Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta UWA ??? IR + 130.38 0.57 ISC UWA MTY ??? IR + 68.27 0.66 ISC MTY HIR ??? IR - 23.20 0.83 ISC HIR NOB ??? IR - 197.56 1.06 ISC NOB ASZ ??? IR - 136.68 1.20 ISC ASZ HMD ??? IR - 1.19 1.29 ISC HMD KUM ??? IR + 235.26 1.36 ISC KUM FKK ??? IR + 269.79 1.39 ISC FKK SAG ??? IR + 256.91 1.49 ISC SAG MRT ??? IR + 100.38 1.82 ISC MRT OKA ??? IR + 54.63 1.90 ISC OKA NGS ??? IR + 245.25 2.01 ISC NGS MTS ??? IR + 24.38 2.04 ISC MTS OIS ??? IR + 78.57 2.78 ISC OIS SAI ??? IR - 21.92 2.81 ISC SAI ABU ??? IR - 65.72 3.19 ISC ABU MAT ??? IR + 58.10 5.85 ISC MAT MBC ??? IR + 14.90 61.90 ISC MBC ALE ??? IR + 2.08 63.91 ISC ALE UME ??? IR + 333.84 69.14 ISC UME BLC ??? IR + 19.57 75.37 ISC BLC FBC ??? IR + 9.06 81.64 ISC FBC sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
