Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta VNA1 ??? IR + 154.69 14.00 ISC VNA1 SNA ??? IR - 148.38 15.25 ISC SNA NVL ??? IR + 142.53 19.68 ISC NVL SYO ??? IR - 137.48 29.13 ISC SYO SPA ??? IR - 179.99 31.29 ISC SPA TUH ??? IR + 69.94 39.48 ISC TUH CER ??? IR + 70.15 39.50 ISC CER RTCB ??? IR - 294.97 39.52 ISC RTCB SUR ??? IR + 70.88 41.04 ISC SUR POF ??? IR + 67.45 43.09 ISC POF FRS ??? IR + 73.30 45.41 ISC FRS BLF ??? IR + 73.65 46.37 ISC BLF SWZ ??? IR + 71.32 47.53 ISC SWZ WIN ??? IR + 59.43 47.58 ISC WIN SEK ??? IR + 74.47 47.73 ISC SEK PRY ??? IR + 73.27 48.80 ISC PRY KSR ??? IR + 71.92 49.41 ISC KSR SLR ??? IR + 73.20 50.19 ISC SLR BFT ??? IR + 74.88 51.11 ISC BFT ZOBO ??? IR + 306.15 52.42 ISC ZOBO BUL ??? IR d 69.78 55.06 ISC BUL LIC ??? IR + 23.09 67.12 ISC LIC KIC ??? IR + 23.36 67.31 ISC KIC TIC ??? IR + 23.01 67.53 ISC TIC BFD ??? IR - 171.09 83.84 ISC BFD ASPA ??? IR - 161.83 96.14 ISC ASPA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
