Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta HNR ??? IR + 287.81 4.43 ISC HNR BKM ??? IR c 150.65 7.84 ISC BKM DZM ??? IR d 169.50 11.38 ISC DZM CTA ??? IR + 239.82 19.60 ISC CTA RMQ ??? IR + 221.03 21.35 ISC RMQ WB2 ??? IR - 248.89 30.15 ISC WB2 TOO ??? IR - 209.22 31.51 ISC TOO ADE ??? IR - 219.96 33.42 ISC ADE AFR ??? IR + 103.96 45.01 ISC AFR PAE ??? IR + 104.12 45.20 ISC PAE TVO ??? IR + 104.27 45.52 ISC TVO PMO ??? IR + 100.42 46.79 ISC PMO VAH ??? IR + 100.74 47.04 ISC VAH TPT ??? IR + 100.40 47.05 ISC TPT RUV ??? IR + 100.68 47.28 ISC RUV SSE ??Z IR + 316.73 58.66 ISC SSE KMI ??Z IR + 301.89 69.73 ISC KMI HHC ??? IR - 320.28 70.70 ISC HHC SVW ??? IR + 18.65 78.37 ISC SVW SHL ??? IR D 298.78 79.10 ISC SHL ZAK ??? IR + 325.45 80.67 ISC ZAK ZAK SPZ IR C 325.45 80.67 MOS ZAK TIK ??? IR + 349.40 85.58 ISC TIK TIK SPZ IR C 349.40 85.58 MOS TIK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
