Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta JHE ??? IR c 298.90 0.66 ISC JHE JWY ??? IR c 260.15 0.67 ISC JWY JEG ??? IR c 0.22 0.80 ISC JEG JWZ ??? IR c 215.02 0.98 ISC JWZ JAI ??? IR c 251.91 1.69 ISC JAI JJS ??? IR c 271.77 2.03 ISC JJS JMN ??? IR c 254.49 2.17 ISC JMN JHS ??? IR c 284.71 2.78 ISC JHS SAI ??? IR c 307.60 3.11 ISC SAI JTO ??? IR c 244.80 3.33 ISC JTO INCN ??? IR - 294.44 8.51 ISC INCN MDJ ??Z IR + 334.98 11.53 ISC MDJ SNY ??Z IR - 310.32 12.55 ISC SNY NJ2 ??Z IR + 266.07 14.86 ISC NJ2 WHN ??Z IR - 264.61 18.97 ISC WHN BAG ??? IR d 222.42 22.80 ISC BAG GYA ??Z IR - 261.00 26.74 ISC GYA CD2 ??Z IR - 272.05 27.63 ISC CD2 KMI ??Z IR - 261.59 30.51 ISC KMI OBN ??? IR + 322.29 67.76 ISC OBN DAG ??? IR - 353.99 68.06 ISC DAG HBMT ??? IR + 41.74 78.84 ISC HBMT LRM ??? IR + 41.65 78.91 ISC LRM BW06 ??? IR + 42.71 82.45 ISC BW06 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
