Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta TATO ??? IR c 250.36 3.99 NEIC TATO SSE ??? IR d 321.36 6.10 NEIC SSE QZH ??? IR c 258.83 6.51 BJI QZH BBP ??? IR c 210.38 6.80 MAN BBP NJ2 ??? IR c 315.27 8.18 BJI NJ2 PIP ??? IR c 211.02 9.26 MAN PIP CVP ??? IR c 202.97 9.33 MAN CVP BAG ??? IR d 206.32 10.97 MAN BAG BCPH ??? IR d 206.25 11.00 MAN BCPH SNY ??? IR D 354.26 15.50 BJI SNY TIY ??? IR d 318.59 15.88 BJI TIY GYA ??? IR D 274.49 16.99 BJI GYA HHC ??? IR d 324.59 18.55 BJI HHC CD2 ??? IR D 288.32 19.71 BJI CD2 KMI ??? IR d 271.57 20.65 BJI KMI LZH ??? IR d 302.79 20.95 NEIC LZH IRK M?Z IR D 333.77 30.43 MOS IRK SVE ??? IR d 322.39 54.71 NEIC SVE ZEI S?Z IR C 307.57 66.79 MOS ZEI OBN B?Z IR D 321.80 68.27 MOS OBN OJC ??? IR c 321.06 79.54 WAR OJC MOX ??? IR + 324.19 83.78 JEN MOX MOX ??? IR C 324.19 83.78 JEN MOX MOA ??? IR C 320.88 83.88 VIE MOA KBA ??? IR C 320.58 84.83 VIE KBA WTTA ??? IR C 321.39 85.69 VIE WTTA MOTA ??? IR C 321.67 85.94 VIE MOTA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
