Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CAO S?Z IR D 38.20 0.34 CASC CAO EPA S?Z IR C 52.05 0.90 CASC EPA VACR S?Z IR D 31.29 1.21 CASC VACR POA2 S?Z IR D 54.72 1.29 CASC POA2 LARO S?Z IR D 77.84 1.30 CASC LARO SJS B?Z IR C 67.83 1.34 CASC SJS OCM S?Z IR D 70.88 1.42 CASC OCM IRZ2 S?Z IR D 68.99 1.50 CASC IRZ2 PALO S?Z IR C 76.48 1.52 CASC PALO TLLA S?Z IR D 69.35 1.62 CASC TLLA VTU S?Z IR D 69.00 1.65 CASC VTU FIBO S?Z IR D 69.65 1.69 CASC FIBO TIG S?Z IR C 100.94 2.03 CASC TIG CONN S?Z IR C 351.90 2.14 CASC CONN CTCR S?Z IR C 101.68 2.58 CASC CTCR CRUN S?Z IR D 339.25 2.71 CASC CRUN TICN S?Z IR C 340.93 2.74 CASC TICN COFN S?Z IR D 344.00 2.81 CASC COFN MGAN S?Z IR C 341.39 2.85 CASC MGAN TISN S?Z IR C 340.95 2.85 CASC TISN XAVN S?Z IR C 339.94 2.88 CASC XAVN APYN S?Z IR C 340.09 2.96 CASC APYN MOMJ S?Z IR C 338.03 3.19 CASC MOMJ MIRN S?Z IR C 335.53 3.29 CASC MIRN CNGN S?Z IR C 336.16 3.34 CASC CNGN PYN S?Z IR C 330.44 3.38 CASC PYN TEL3 S?Z IR C 334.48 3.46 CASC TEL3 TELN S?Z IR D 334.91 3.49 CASC TELN AGUN S?Z IR D 335.26 3.54 CASC AGUN CRIN S?Z IR D 332.53 3.67 CASC CRIN MOCN S?Z IR D 333.25 3.73 CASC MOCN QUIN S?Z IR C 343.74 3.83 CASC QUIN SOMN S?Z IR D 342.35 4.16 CASC SOMN AZU S?Z IR C 107.70 5.25 CASC AZU SVW ??? IR d 331.32 72.31 NEIC SVW CLL ??? IR - 38.43 87.87 CLL CLL sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
