Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CEP ??? IR + 151.45 4.11 MSSP CEP THW ??? IR + 158.29 4.99 MSSP THW AKL S?? IR C 156.72 17.92 NDI AKL SVE ??? IR d 345.76 20.26 NEIC SVE ARU ??? IR d 342.27 20.35 NEIC ARU PYA ??? IR c 296.46 21.06 NEIC PYA HYB ??? IR C 155.93 21.49 HYB HYB SHL S?? IR C 115.61 22.37 NDI SHL KMI ??? IR D 103.98 30.75 BJI KMI CFR ??? IR + 297.27 31.76 BUC CFR VRI ??? IR + 298.58 32.74 BUC VRI ISR ??? IR - 297.21 32.89 BUC ISR GYA ??? IR C 98.45 33.15 BJI GYA MLR ??? IR + 297.92 33.30 BUC MLR SNX ??? IR + 297.69 33.61 BUC SNX BOD S?Z IR D 40.37 35.35 MOS BOD ARSA ??? IR C 301.67 40.38 VIE ARSA OBKA ??? IR C 300.67 41.13 VIE OBKA MOA ??? IR C 302.73 41.16 VIE MOA SNY ??? IR c 66.52 41.26 BJI SNY SGO ??? IR C 291.68 41.71 ROM SGO KBA ??? IR C 301.69 41.87 VIE KBA WTTA ??? IR C 302.21 43.00 VIE WTTA MOTA ??? IR C 302.40 43.34 VIE MOTA IPM ??? IR d 131.05 43.65 KLM IPM DAVA ??? IR C 302.52 44.18 VIE DAVA TIXI B?Z IR C 22.52 45.32 MOS TIXI YSS ??? IR c 54.97 53.22 NEIC YSS DAG ??? IR D 343.36 53.48 DNK DAG MA2 S?Z IR D 38.26 54.32 MOS MA2 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
