Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta APON S?Z IR C 353.67 0.31 CASC APON SSNN S?Z IR C 150.47 0.36 CASC SSNN MASN S?Z IR C 342.86 0.40 CASC MASN CONN S?Z IR C 95.81 0.40 CASC CONN TICN S?Z IR C 335.31 0.47 CASC TICN MADN S?Z IR C 111.78 0.53 CASC MADN WILN S?Z IR C 344.57 0.57 CASC WILN MGAN S?Z IR C 338.62 0.58 CASC MGAN XAVN S?Z IR C 331.93 0.61 CASC XAVN COPN S?Z IR D 316.24 0.79 CASC COPN PYTN S?Z IR C 358.43 0.93 CASC PYTN MOMJ S?Z IR C 328.12 0.94 CASC MOMJ MIRN S?Z IR D 321.35 1.06 CASC MIRN CNGN S?Z IR C 323.81 1.10 CASC CNGN LEON S?Z IR C 313.82 1.17 CASC LEON TEL3 S?Z IR C 320.47 1.25 CASC TEL3 TELN S?Z IR C 321.85 1.26 CASC TELN CRIN S?Z IR C 317.64 1.48 CASC CRIN VCR S?Z IR C 164.98 1.52 CASC VCR JTS ??? IR c 140.84 1.68 NEIC JTS SJS S?Z IR C 130.25 2.55 CASC SJS SAML ??? IR c 130.99 30.55 NEIC SAML HBO ??? IR d 322.58 44.81 NEIC HBO IRO ??? IR c 322.81 44.87 NEIC IRO HOOD ??? IR d 324.67 45.28 NEIC HOOD RNO ??? IR d 321.86 45.70 NEIC RNO ASR ??? IR d 325.64 45.75 NEIC ASR MPOR ??? IR d 322.65 45.92 NEIC MPOR HDW ??? IR d 326.45 47.45 NEIC HDW MCW ??? IR d 327.69 47.96 NEIC MCW DAG ??? IR c 12.80 73.66 NEIC DAG DAG ??? IR C 12.80 73.66 DNK DAG DAG S?Z IR C 12.80 73.66 MOS DAG DAVA HHZ IR d 42.78 85.54 VIE DAVA DAVA HHZ IR c 42.78 85.54 VIE DAVA WATA EHZ IR c 42.48 86.66 VIE WATA WATA EHZ IR c 42.48 86.66 VIE WATA WTTA HHZ IR d 42.54 86.72 VIE WTTA WTTA HHZ IR c 42.54 86.72 VIE WTTA KBA HHZ IR c 42.44 87.89 VIE KBA KBA HHZ IR d 42.44 87.89 VIE KBA MOA HHZ IR c 41.53 88.30 VIE MOA MOA HHZ IR d 41.53 88.30 VIE MOA TIXI S?Z IR D 349.54 93.72 MOS TIXI VNA3 ??? IR + 161.55 96.57 AWI VNA3 VNA1 ??? IR + 160.85 96.85 AWI VNA1 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
