Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta KAKA ??? IR D 217.61 11.90 AUST KAKA CTA ??? IR D 159.99 17.84 AUST CTA CTA S?Z IR D 159.99 17.84 MOS CTA CGP ??? IR d 307.72 19.08 MAN CGP SCPH ??? IR c 312.33 19.31 MAN SCPH RCP ??? IR c 311.15 22.51 MAN RCP MYLDM HHZ IR C 291.41 22.92 KLM MYLDM TSM ELZ IR D 288.75 23.21 KLM TSM SDKM ELZ IR C 291.32 24.30 KLM SDKM KDM ELZ IR D 293.81 25.11 KLM KDM KKM HHZ IR D 291.38 25.35 KLM KKM BTM ELZ IR C 283.26 27.52 KLM BTM SBUM HHZ IR C 281.30 28.20 KLM SBUM KSM HHZ IR D 278.63 29.90 KLM KSM ADE S?Z IR C 181.79 31.55 MOS ADE KGM ELZ IR C 277.70 36.89 KLM KGM KTGM ELZ IR C 283.00 37.66 KLM KTGM SSE ??? IR D 333.85 38.53 BJI SSE SSE ??? IR d 333.85 38.53 NEIC SSE FRIM ELZ IR C 279.24 38.75 KLM FRIM IPM HHZ IR C 281.00 39.55 KLM IPM WHN ??? IR C 325.92 41.52 BJI WHN NANT ??? IR c 301.15 44.33 BKK NANT CHRT ??? IR c 301.98 45.58 BKK CHRT KMI ??? IR C 310.22 45.75 BJI KMI KMI S?Z IR C 310.22 45.75 MOS KMI KMI ??? IR c 310.22 45.75 NEIC KMI CHG ??? IR c 300.18 45.85 BKK CHG VLA ??? IR c 351.99 46.74 NEIC VLA SNY ??? IR D 343.44 47.27 BJI SNY JCZ ??? IR c 152.01 48.00 WEL JCZ CD2 ??? IR C 317.36 48.36 BJI CD2 CN2 ??? IR D 346.11 48.62 BJI CN2 YSS M?Z IR D 2.59 50.08 MOS YSS YSS M?Z IR D 2.59 50.08 MOS YSS LZH ??? IR C 322.59 51.62 BJI LZH LZH S?Z IR C 322.59 51.62 MOS LZH LZH ??? IR c 322.59 51.62 NEIC LZH KLR M?Z IR C 353.34 52.76 MOS KLR GTA ??? IR C 323.15 56.20 BJI GTA ZAK S?Z IR D 334.40 61.98 MOS ZAK TLY B?Z IR C 335.57 62.80 MOS TLY MA2 B?Z IR D 6.20 63.25 MOS MA2 MA2 B?Z IR D 6.20 63.25 MOS MA2 HYB S?Z IR C 291.09 63.84 MOS HYB HYB ??? IR c 291.09 63.84 HYB HYB JBP B?Z IR C 297.64 63.95 NDI JBP YAK B?Z IR D 354.76 65.59 MOS YAK SEY S?Z IR C 6.20 66.71 MOS SEY SEY S?Z IR C 6.20 66.71 MOS SEY MIR S?Z IR C 197.98 71.01 MOS MIR BILL B?Z IR C 10.05 73.52 MOS BILL NVS S?Z IR C 329.88 74.25 MOS NVS FRU S?Z IR C 316.09 74.38 MOS FRU AAK S?Z IR C 315.87 74.40 MOS AAK COLA S?Z IR C 24.08 85.51 MOS COLA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
