Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta DMPH ??? IR d 302.47 0.83 MAN DMPH GSPH ??? IR d 246.78 1.37 MAN GSPH BIPH ??? IR c 5.29 1.55 MAN BIPH CTBH ??? IR d 286.74 2.04 MAN CTBH CGP ??? IR c 320.27 2.36 MAN CGP DCPH ??? IR d 304.48 3.44 MAN DCPH RCP ??? IR c 325.25 5.98 MAN RCP MYLDM HHZ IR C 259.76 7.81 KLM MYLDM TSM ELZ IR D 254.79 8.62 KLM TSM SDKM ELZ IR C 264.22 9.03 KLM SDKM KDM ELZ IR D 272.28 9.32 KLM KDM KKM HHZ IR C 267.19 9.96 KLM KKM PCPH ??? IR c 330.92 10.20 MAN PCPH BTM ELZ IR C 256.02 13.52 KLM BTM SBUM HHZ IR C 254.05 14.56 KLM SBUM KSM HHZ IR C 252.78 16.67 KLM KSM KAKA ??? IR D 162.15 20.19 AUST KAKA MYKOM HHZ IR C 258.81 22.81 KLM MYKOM KTGM ELZ IR C 268.02 22.99 KLM KTGM KGM ELZ IR D 259.66 23.28 KLM KGM FRIM ELZ IR C 263.35 24.73 KLM FRIM KULM HHZ IR D 268.39 25.46 KLM KULM GYA ??? IR C 318.85 27.12 BJI GYA CHRT ??? IR d 299.70 28.84 BKK CHRT CHG ??? IR d 297.07 29.17 BKK CHG SNY ??? IR C 356.57 35.13 BJI SNY LZH ??? IR D 328.17 35.77 BJI LZH FORT ??? IR D 177.38 37.24 AUST FORT KLBR ??? IR D 191.55 38.86 AUST KLBR MUN ??? IR C 193.41 39.56 AUST MUN STKA ??? IR D 159.89 41.01 AUST STKA CNB ??? IR D 153.96 47.08 AUST CNB ARU B?Z IR C 327.35 72.23 MOS ARU DAG ??? IR C 352.36 94.33 DNK DAG sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
