Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CKHZ ??? IR c 140.93 1.01 WEL CKHZ KAHZ ??? IR c 152.42 1.03 WEL KAHZ KNZ ??? IR c 97.85 1.11 WEL KNZ WPHZ ??? IR c 173.15 1.19 WEL WPHZ PRGZ ??? IR d 92.53 1.27 WEL PRGZ WAZ ??? IR c 227.96 1.32 WEL WAZ RAEZ ??? IR d 253.68 1.50 WEL RAEZ CNGZ ??? IR d 76.17 1.58 WEL CNGZ NEZ ??? IR c 256.20 1.73 WEL NEZ PKE ??? IR d 259.16 1.79 WEL PKE BFZ ??? IR c 180.22 1.80 WEL BFZ NWEZ ??? IR d 257.21 1.90 WEL NWEZ TIWZ ??? IR c 188.42 1.92 WEL TIWZ HOWZ ??? IR c 195.53 2.10 WEL HOWZ OGWZ ??? IR d 202.98 2.11 WEL OGWZ KUZ ??? IR d 348.59 2.17 WEL KUZ OTAZ ??? IR c 330.93 2.19 WEL OTAZ TMWZ ??? IR c 187.06 2.24 WEL TMWZ WTAZ ??? IR d 325.07 2.35 WEL WTAZ KAAZ ??? IR d 328.62 2.39 WEL KAAZ TRWZ ??? IR c 189.62 2.56 WEL TRWZ PAWZ ??? IR c 193.98 2.58 WEL PAWZ DUWZ ??? IR d 222.34 2.63 WEL DUWZ MRW ??? IR d 206.44 2.63 WEL MRW BHW ??? IR d 202.33 2.74 WEL BHW TCW ??? IR d 212.47 2.78 WEL TCW NNZ ??? IR d 222.46 3.21 WEL NNZ THZ ??? IR c 220.56 3.85 WEL THZ DSZ ??? IR d 228.50 4.45 WEL DSZ SNAA B?Z IR D 180.31 69.75 MOS SNAA SNAA ??? IR d 180.31 69.75 NEIC SNAA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
