Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta AAI ??? IR D 343.63 3.62 DJA AAI KAKA ??? IR D 150.22 6.34 AUST KAKA KDI ??? IR C 295.70 7.31 DJA KDI TNE ??? IR C 346.82 8.13 DJA TNE PCI ??? IR D 303.30 11.24 DJA PCI FITZ ??? IR D 197.49 11.39 AUST FITZ TRT ??? IR C 267.15 16.45 DJA TRT CTA ??? IR D 129.51 20.91 AUST CTA FORT ??? IR D 182.50 23.49 AUST FORT STKA ??? IR D 156.44 27.14 AUST STKA PSI ??? IR C 287.14 31.82 DJA PSI TOO ??? IR D 156.32 33.66 AUST TOO BSI ??? IR D 289.53 36.12 DJA BSI CHG ??? IR c 311.32 39.48 BKK CHG GYA ??? IR d 327.64 39.97 BJI GYA WHN ??? IR d 339.92 40.13 BJI WHN CD2 ??? IR c 328.53 45.05 BJI CD2 SHL B?Z IR C 313.24 48.76 NDI SHL GTA ??? IR c 331.87 53.77 BJI GTA SEY S?Z IR C 10.90 72.14 MOS SEY KURK B?Z IR C 328.95 72.28 MOS KURK BILL S?Z IR D 13.33 79.47 MOS BILL SVE S?Z IR C 329.06 84.53 MOS SVE ARU B?Z IR D 328.27 85.46 MOS ARU OBN S?Z IR D 324.64 97.36 MOS OBN sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
