Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta ARCH ??Z IR D 129.39 3.96 GUC ARCH PB01 HHZ CX -- - a 143.34 6.32 ISC PB01 PB01 BHZ CX -- - a 143.34 6.32 ISC PB01 PB07 BHZ CX -- - a 149.48 6.66 ISC PB07 PB07 HHZ CX -- - a 149.48 6.66 ISC PB07 PB03 BHZ CX -- - a 150.00 7.00 ISC PB03 PB03 HHZ CX -- - a 150.00 7.00 ISC PB03 PB09 HHZ CX -- - a 145.63 7.05 ISC PB09 PB09 BHZ CX -- - a 145.63 7.05 ISC PB09 PB04 BHZ CX -- - a 153.75 7.07 ISC PB04 PB04 HHZ CX -- - a 153.75 7.07 ISC PB04 MACH S?Z IR C 150.64 7.12 GUC MACH MECH S?Z IR D 158.24 7.65 GUC MECH PB06 BHZ CX -- - a 151.47 7.65 ISC PB06 PB06 HHZ CX -- - a 151.47 7.65 ISC PB06 PB10 BHZ CX -- - a 160.02 7.99 ISC PB10 PB10 HHZ CX -- - a 160.02 7.99 ISC PB10 ANCH S?Z IR D 159.56 8.19 GUC ANCH MONA BHZ ZL -- - a 163.72 15.57 ISC AMOG LLAN BHZ ZL -- + a 157.14 15.71 ISC APLL 626A BHZ TA -- - a 326.77 54.06 ISC 626A N18A BHZ TA -- - a 330.69 65.85 ISC N18A R11A BHZ TA -- - a 325.06 66.90 ISC R11A E028 HHZ IB -- - a 46.75 82.54 ISC E028 SYO BHZ PS -- + a 160.50 83.15 ISC SYO ELOJ HHZ IB -- - a 48.77 83.90 ISC ELOJ PAB BHZ IU 00 + a 46.53 84.79 ISC PAB TAM BHZ G 00 + a 65.21 86.38 ISC TAM SUMG S?Z IR C 9.97 91.37 MOS SUMG SUMG ??? IR C 9.97 91.37 DNK SUMG MOTA ??? IR c 43.14 98.01 VIE MOTA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
