Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta FIB BHZ AK -- + a 149.87 0.47 ISC FIB PMR BHZ AT -- + a 87.91 0.73 ISC PMR SPBG BHZ AV -- + a 249.66 0.88 ISC SPBG PPLA BHZ AK -- + a 332.43 1.51 ISC PPLA TRF BHZ AK -- + a 5.16 1.89 ISC TRF CAST BHZ AK -- + a 341.07 1.96 ISC CAST MCK BHZ AK -- - a 19.48 2.31 ISC MCK DIV BHZ AK -- + a 98.57 2.40 ISC DIV CHUM BHZ AK -- + a 342.59 2.44 ISC CHUM EYAK BHZ AK -- + a 111.12 2.60 ISC EYAK PAX BHZ AK -- - a 57.76 2.81 ISC PAX BMR BHZ AK -- + a 99.07 2.99 ISC BMRM GOAT BHZ XZ -- + a 106.44 3.05 ISC GOAT VRDI BHZ XZ -- + a 92.55 3.49 ISC VRDI BERG BHZ XZ -- - a 106.19 3.59 ISC BERG DOT BHZ AK -- - a 52.80 3.69 ISC DOT KHIT BHZ XZ -- - a 104.18 3.79 ISC KHIT GRIN BHZ XZ -- - a 106.66 3.81 ISC GRIN PTPK BHZ XZ -- - a 92.02 3.96 ISC PTPK KIAG BHZ XZ -- + a 95.59 4.07 ISC KIAG KULT BHZ XZ -- + a 105.44 4.10 ISC KULT BARK BHZ XZ -- - a 102.84 4.15 ISC BARK BAGL BHZ XZ -- + a 100.84 4.31 ISC BAGL SAMH BHZ XZ -- + a 102.33 5.05 ISC SAMH EGAK BHZ US -- - a 49.12 5.37 ISC EGAK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
