Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta YLYR S?Z IR D 87.95 0.73 MOS YLYR YLYR ??? IR c 87.95 0.73 BYKL YLYR YLYR ??? IR d 87.95 0.73 BYKL YLYR YLYR ??? IR d 87.95 0.73 BYKL YLYR NIZ S?Z IR C 347.64 0.94 MOS NIZ NIZ ??? IR c 347.64 0.94 BYKL NIZ NIZ ??Z IR C 347.64 0.94 BYKL NIZ SYVR ??? IR c 177.15 1.20 BYKL SYVR KMO ??? IR c 35.21 1.27 BYKL KMO YOA S?Z IR C 38.33 1.65 MOS YOA YOA ??? IR c 38.33 1.65 BYKL YOA OGRR ??? IR c 228.97 1.82 BYKL OGRR OGRR ??? IR d 228.97 1.82 BYKL OGRR OGRR ??? IR d 228.97 1.82 BYKL OGRR UKT S?Z IR C 71.97 2.23 MOS UKT UKT ??? IR c 71.97 2.23 BYKL UKT UKT ??? IR c 71.97 2.23 BYKL UKT UKT ??? IR c 71.97 2.23 BYKL UKT SVKR ??? IR d 57.27 2.44 BYKL SVKR TRG ??? IR c 226.50 2.97 BYKL TRG UUDB ??? IR c 205.00 3.28 BYKL UUDB HRMR ??? IR c 209.86 3.69 BYKL HRMR HRMR ??? IR c 209.86 3.69 BYKL HRMR BOD ??? IR c 35.90 3.75 BYKL BOD CRS ??? IR c 63.10 5.14 BYKL CRS ARS ??? IR c 239.73 5.35 BYKL ARS KPC ??? IR c 162.56 5.38 BYKL KPC KPC ??? IR d 162.56 5.38 BYKL KPC TUP ??? IR c 90.13 5.86 BYKL TUP MOY ??? IR c 242.76 6.22 BYKL MOY ORL ??? IR d 252.95 6.42 BYKL ORL ORY S?Z IR D 277.03 8.52 MOS ORY MK06 SHZ KZ -- + a 256.40 19.11 ISC MK06 MK05 SHZ KZ -- + a 256.47 19.12 ISC MK05 MK01 SHZ KZ -- + a 256.40 19.12 ISC MK01 MK07 SHZ KZ -- + a 256.34 19.13 ISC MK07 MK03 SHZ KZ -- + a 256.39 19.13 ISC MK03 MK04 SHZ KZ -- - a 256.41 19.13 ISC MK04 MK09 SHZ KZ -- + a 256.44 19.14 ISC MK09 CHKZ2 SHZ KZ -- + a 283.27 22.75 ISC CHK5 CHKZ1 SHZ KZ -- + a 283.33 22.75 ISC CHK4 CHKZ6 SHZ KZ -- + a 283.36 22.77 ISC CHK9 CHKZ4 SHZ KZ -- + a 283.26 22.80 ISC CHK7 BVA6 SHZ KZ -- - a 281.88 23.12 ISC BVB6 BRVK SHZ II 00 + a 281.98 23.17 ISC BRVK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
