Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta MCQ S?Z IR C 200.65 1.02 MOS MCQ MCQ ??? IR c 200.65 1.02 NEIC MCQ MILA SHZ IR d 332.12 18.02 AUST MILA TOO BHZ IR c 322.96 18.72 AUST TOO URZ HHZ NZ 10 + a 45.35 19.48 ISC URZ CAN BHZ IR c 333.56 19.69 AUST CAN RIV SHZ IR c 339.75 20.60 AUST RIV YNG BHZ IR c 333.16 20.81 AUST YNG MGCD SHZ IR d 340.07 21.21 AUST MGCD ARMA BHZ IR c 342.82 23.83 AUST ARMA VNDA SHZ GT 10 + a 178.78 24.08 ISC VNDA VNDA BHZ GT 00 + a 178.78 24.08 ISC VNDA HTT SHZ IR c 315.57 24.91 AUST HTT BBOO BHZ IR d 311.56 26.68 AUST BBOO RMQ SHZ IR c 339.16 28.21 AUST RMQ EIDS BHZ IR d 343.94 28.86 AUST EIDS QLP BHZ IR c 331.01 29.25 AUST QLP FORT BHZ IR d 302.36 32.17 AUST FORT CTA BHZ IR c 337.79 34.94 AUST CTA CTA BHZ AU -- + a 337.79 34.94 ISC CTA KMBL BHZ IR c 294.12 34.96 AUST KMBL RKGY SHZ IR d 285.03 35.31 AUST RKGY WRKA BHZ IR c 308.24 36.84 AUST WRKA KLBR SHZ IR d 289.31 37.08 AUST KLBR MTSU SHZ IR c 335.60 37.28 AUST MTSU BLDU BHZ IR c 289.25 38.40 AUST BLDU MORW BHZ IR d 290.12 39.95 AUST MORW MEEK BHZ IR d 295.22 40.43 AUST MEEK KNRA BHZ IR d 315.60 44.83 AUST KNRA KDU SHZ IR c 321.90 46.09 AUST KDU MTN BHZ IR c 320.15 46.45 AUST MTN EFI S?Z IR C 156.21 70.51 MOS EFI DGAR S?Z IR C 267.89 82.38 MOS DGAR MAJO S?Z IR C 342.93 91.62 MOS MAJO sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
