Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta VNA3 BHZ AW -- - a 159.86 16.67 ISC VNA3 VNAC7 SHZ AW -- + a 157.16 16.88 ISC VNA2 VNAC6 SHZ AW -- + a 157.18 16.88 ISC VNA2 VNAB5 SHZ AW -- + a 157.16 16.88 ISC VNA2 VNAC1 SHZ AW -- + a 157.14 16.88 ISC VNA2 VNAA1 SHZ AW -- + a 157.16 16.88 ISC VNA2 VNAB1 SHZ AW -- + a 157.15 16.88 ISC VNA2 VNAB4 SHZ AW -- + a 157.18 16.88 ISC VNA2 VNA2 BHZ AW -- + a 157.16 16.88 ISC VNA2 VNAA3 SHZ AW -- + a 157.17 16.88 ISC VNA2 VNAA2 SHZ AW -- + a 157.16 16.89 ISC VNA2 VNAB3 SHZ AW -- + a 157.17 16.89 ISC VNA2 VNAC4 SHZ AW -- + a 157.18 16.89 ISC VNA2 VNAC3 SHZ AW -- + a 157.16 16.89 ISC VNA2 NVL S?Z IR C 145.97 22.02 MOS NVL SYO BHZ PS -- + a 140.40 31.37 ISC SYO SBA BHZ IU 00 + a 184.16 45.68 ISC SBA VNDA BHZ GT 00 + a 182.79 46.18 ISC VNDA PRYS B?Z IR C 76.30 48.67 PRE PRYS LBTB BHZ GT 00 + a 73.11 49.26 ISC LBTB LBTB B?Z IR C 73.11 49.26 PRE LBTB ERPM B?Z IR D 76.67 49.61 PRE ERPM SLR B?Z IR C 76.23 50.12 PRE SLR LPAZ BHZ GT 00 - a 305.75 50.49 ISC LPAZ DRV BHZ G 00 + a 174.06 56.85 ISC DRV LSZ BHZ IU 00 + a 68.88 58.65 ISC LSZ LSZ B?Z IR C 68.88 58.65 PRE LSZ DBIC B?Z IR D 24.77 65.58 PRE DBIC SDV HHZ IU 10 - a 315.34 74.19 ISC SDV SDV BHZ IU 10 - a 315.34 74.19 ISC SDV HDC BHZ G 00 - a 303.56 80.96 ISC HDC JTS B?Z IR D 302.96 81.61 MOS JTS SARO BHZ YZ -- - a 302.64 82.40 ISC NY17 TAM BHZ G 00 - a 30.35 83.70 ISC TAM sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
