Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta TTO3 ??? IR C 130.53 0.32 JMA TTO3 TTO2 ??? IR C 190.81 0.34 JMA TTO2 TTO4 ??? IR C 100.02 0.37 JMA TTO4 JIE ??? IR C 314.12 0.46 JMA JIE TTO1 ??? IR C 210.73 0.52 JMA TTO1 TK02 ??? IR C 102.86 0.56 JMA TK02 JWY ??? IR C 277.04 1.26 JMA JWY INU BHZ G 00 + a 357.23 1.28 ISC INU JWZ ??? IR C 245.34 1.28 JMA JWZ JGM ??? IR C 349.04 1.65 JMA JGM JWT ??? IR C 311.18 1.85 JMA JWT JOD2 ??? IR D 53.45 2.02 JMA JOD2 JAI ??? IR C 263.51 2.22 JMA JAI JMN ??? IR C 263.60 2.70 JMA JMN CD2 ??? IR d 272.90 28.23 BJI CD2 MKAR BHZ KZ -- + a 304.25 42.79 ISC MKAR KUR09 BHZ KZ -- - a 309.80 45.14 ISC KUR09 KUR20 BHZ KZ -- + a 309.95 45.22 ISC KUR20 WB7 BHZ AU -- + a 183.18 53.67 ISC WB7 WB6 BHZ AU -- + a 183.20 53.69 ISC WB6 WB5 BHZ AU -- + a 183.20 53.71 ISC WB5 WC1 BHZ AU -- - a 183.23 53.76 ISC WC1 WR3 BHZ AU -- + a 183.17 53.78 ISC WR3 WC4 BHZ AU -- - a 183.22 53.80 ISC WC4 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
