Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta RABL BHZ AU -- - a 334.98 1.03 ISC RABL QIS BHZ AU -- - a 218.32 19.87 ISC QIS DZM BHZ G 00 + a 142.77 21.52 ISC DZM WB9 BHZ AU -- + a 229.00 22.95 ISC WB9 WB8 BHZ AU -- + a 228.96 22.97 ISC WB8 WB7 BHZ AU -- + a 228.91 22.99 ISC WB7 WB6 BHZ AU -- + a 228.90 23.00 ISC WB6 WR5 BHZ AU -- - a 228.61 23.02 ISC WR5 WR4 BHZ AU -- + a 228.65 23.03 ISC WR4 WC2 BHZ AU -- - a 228.76 23.05 ISC WC2 WR2 BHZ AU -- - a 228.72 23.06 ISC WR2 WC1 BHZ AU -- - a 228.80 23.07 ISC WC1 WC4 BHZ AU -- - a 228.72 23.09 ISC WC4 KNRA BHZ AU -- + a 244.07 25.65 ISC KNRA MEEK BHZ AU -- - a 232.91 38.85 ISC MEEK CMAR B?Z IR C 295.42 57.84 MOS CMAR ULN S?Z IR C 328.30 66.17 MOS ULN MKAR B?Z IR C 319.00 80.44 MOS MKAR COLA B?Z IR C 21.81 82.23 MOS COLA AAK B?Z IR D 313.52 84.75 MOS AAK BRVK B?Z IR D 323.26 89.45 MOS BRVK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
