Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta RDX S?Z IR C 235.59 0.61 ECX RDX COA H?Z IR D 18.29 0.62 ECX COA COK H?Z IR D 331.39 0.66 ECX COK RMX S?Z IR D 298.41 0.69 ECX RMX IBP BHZ IR c 301.99 0.73 IRIS IBP YMD H?Z IR C 67.47 0.74 ECX YMD SWSC BHZ IR c 330.82 0.77 IRIS SWSC GLA BHZ IR c 29.67 0.90 IRIS GLA MONP2 BHZ IR c 304.68 1.09 IRIS MONP2 BC3 BHZ IR c 356.56 1.38 IRIS BC3 113A BHZ IR d 69.36 1.43 IRIS 113A HWB BHZ AZ -- - a 299.44 1.55 ISC HWB 109C BHZ IR d 293.03 1.60 IRIS 109C PFO BHZ IR c 325.46 1.63 IRIS PFO Y12C BHZ IR d 25.12 1.63 IRIS Y12C BELC BHZ IR c 342.76 1.81 IRIS BELC IRM BHZ IR c 5.27 1.89 IRIS IRM MURC BHZ IR d 311.02 2.04 IRIS MURC 214A BHZ IR d 97.66 2.18 IRIS 214A Z14A BHZ IR c 61.17 2.30 IRIS Z14A BBRC BHZ IR c 326.94 2.38 IRIS BBRC GMRC BHZ IR c 354.26 2.52 IRIS GMRC NEE2 BHZ IR c 13.67 2.56 IRIS NEE2 Y14A BHZ IR d 49.26 2.58 IRIS Y14A BFSC BHZ IR d 316.06 2.75 IRIS BFSC SCI2 BHZ IR d 285.52 2.79 IRIS SCI2 W18A BHZ TA -- + a 57.26 5.47 ISC W18A sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
