Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta OGS BHZ PS -- + a 235.25 1.20 ISC OGS MAJO S?Z IR C 335.03 9.77 MOS MAJO TJN S?Z IR D 306.48 16.01 MOS TJN VLA S?Z IR D 331.86 17.91 MOS VLA TIA ??? IR d 297.42 23.71 BJI TIA ULN B?Z IR C 315.39 34.55 MOS ULN SEY S?Z IR D 7.10 35.69 MOS SEY CMAR B?Z IR C 266.95 41.66 MOS CMAR TIXI S?Z IR C 353.55 44.67 MOS TIXI WB7 BHZ AU -- - a 191.33 48.09 ISC WB7 WR0 BHZ AU -- + a 191.10 48.18 ISC WR0 WRAB B?Z IR C 191.34 48.19 MOS WRAB MKAR B?Z IR C 309.18 50.84 MOS MKAR KUR11 BHZ KZ -- - a 314.02 53.20 ISC KUR11 KUR12 BHZ KZ -- - a 314.03 53.22 ISC KUR12 KIP S?Z IR D 83.02 53.31 MOS KIP KUR07 BHZ KZ -- - a 314.00 53.31 ISC KUR07 KUR08 BHZ KZ -- - a 313.98 53.32 ISC KUR08 KUR20 BHZ KZ -- - a 314.08 53.40 ISC KUR20 COLA S?Z IR C 28.61 56.26 MOS COLA AAK S?Z IR C 304.59 56.71 MOS AAK BRVK B?Z IR D 317.27 58.30 MOS BRVK ARU B?Z IR D 322.21 64.52 MOS ARU OBN S?Z IR C 325.55 76.56 MOS OBN AKASG B?Z IR C 324.18 82.68 MOS AKASG sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
