Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta COCH B?Z IR C 39.98 0.75 GUC COCH COCH B?Z IR C 39.98 0.75 GUC COCH PLCA SHZ GT 10 + a 152.01 4.59 ISC PLCA PLCA BHZ GT 00 + a 152.01 4.59 ISC PLCA CPUP BHZ GT 00 + a 57.39 17.13 ISC CPUP CPUP BHZ GT 00 + a 57.39 17.13 ISC CPUP EFI S?Z IR D 148.78 18.50 MOS EFI LPAZ SHZ GT 10 + a 14.29 20.87 ISC LPAZ SNAA S?Z IR C 156.91 49.51 MOS SNAA SVB BHZ TR -- + a 15.26 51.01 ISC SVB QSPA BHZ IU 80 + a 180.06 53.53 ISC QSPA QSPA BHZ IU 00 + a 180.06 53.53 ISC QSPA QSPA BHZ IU 10 + a 180.06 53.53 ISC QSPA NVL S?Z IR C 156.00 54.29 MOS NVL SJG BHZ IU 10 - a 8.41 54.94 ISC SJG SYO BHZ PS -- - a 158.29 63.76 ISC SYO KMSC BHZ TA -- - a 353.15 71.86 ISC KMSC ABTX BHZ TA -- + a 337.05 73.21 ISC ABTX WVT BHZ IU 10 - a 347.85 73.70 ISC WVT W39A BHZ TA -- + a 342.72 74.01 ISC W39A LCAR HHZ AG 00 + a 345.11 74.27 ISC LCAR TUL1 BHZ TA -- + a 341.33 75.19 ISC TUL1 121A BHZ TA -- - a 330.54 76.02 ISC 121A ANMO S?Z IR C 332.68 77.65 MOS ANMO PLIO HHZ PO -- - a 352.95 78.54 ISC PLIO T25A BHZ TA -- - a 335.18 78.90 ISC T25A Q24A BHZ TA -- - a 335.43 80.80 ISC Q24A BGNE BHZ TA -- - a 341.39 80.98 ISC BGNE ULM BHZ CN -- - a 345.78 88.83 ISC ULM sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
