Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PMG B?Z IR D 282.04 19.53 MOS PMG CTA BHZ AU -- - a 250.39 20.21 ISC CTA BKZ HHZ NZ 10 + a 162.33 26.37 ISC BKZ WRAB S?Z IR C 254.98 31.23 MOS WRAB KKM HHZ IR c 288.53 53.80 KLM KKM SBUM HHZ IR d 282.74 56.27 KLM SBUM MAJO S?Z IR D 332.96 57.11 MOS MAJO YUK B?Z IR D 343.09 60.95 MOS YUK KTGM ELZ IR d 282.56 65.78 KLM KTGM SNY ??? IR d 326.80 68.37 BJI SNY PSI BHZ PS -- + a 278.51 69.02 ISC RPSI GYA ??? IR c 304.85 70.82 BJI GYA HIA S?Z IR C 330.46 75.48 MOS HIA QSPA BHZ IU 00 - a 180.03 75.81 ISC QSPA QSPA BHZ IU 10 - a 180.03 75.81 ISC QSPA SEY S?Z IR C 353.44 77.69 MOS SEY ULN B?Z IR D 324.08 81.29 MOS ULN YAK B?Z IR C 343.39 81.33 MOS YAK BILL B?Z IR D 359.91 82.03 MOS BILL KTH BHZ AK -- - a 17.73 84.17 ISC KTH TLY B?Z IR C 326.22 85.16 MOS TLY WRH BHZ AK -- + a 18.02 85.69 ISC WRH COLA B?Z IR C 17.82 86.05 MOS COLA TIXI S?Z IR C 348.85 89.32 MOS TIXI SNAA S?Z IR D 183.36 94.02 MOS SNAA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
