Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BGOL ??? IR d 135.10 0.33 AFAD BGOL ECAT ??? IR c 50.35 0.60 AFAD ECAT ERZN BHZ KO -- - a 306.03 0.62 ISC ERZN TNCL ??? IR c 260.81 0.66 AFAD TNCL BNGL ??? IR c 113.79 0.66 AFAD BNGL EUZM ??? IR d 313.03 0.71 AFAD EUZM ERZM ??? IR c 48.06 1.03 AFAD ERZM BAYT BHZ KO -- - a 351.40 1.18 ISC BAYT SVAN BHZ KO -- - a 148.60 1.25 ISC SVAN REFA ??? IR d 278.43 1.26 AFAD REFA KELT ??? IR d 317.38 1.27 AFAD KELT DYBB BHZ KO -- - a 188.29 1.28 ISC DYBB ELZG ??? IR c 236.72 1.30 AFAD ELZG EKAR ??? IR c 88.00 1.31 AFAD EKAR HOMI ??? IR c 54.74 1.44 AFAD HOMI KEMA ??? IR c 272.42 1.46 AFAD KEMA BTMN ??? IR d 151.83 1.50 AFAD BTMN TATV ??? IR c 115.15 1.64 AFAD TATV MACK ??? IR d 345.10 1.78 AFAD MACK TUTA ??? IR c 83.82 1.90 AFAD TUTA MARD ??? IR d 170.35 1.93 AFAD MARD SUSE ??? IR d 301.16 1.94 AFAD SUSE DDEM ??? IR c 31.93 1.98 AFAD DDEM DBAD ??? IR c 29.05 2.06 AFAD DBAD ARTV ??? IR c 30.79 2.29 AFAD ARTV DBOC ??? IR c 24.60 2.34 AFAD DBOC SIRN ??? IR d 136.42 2.35 AFAD SIRN TVAN ??? IR c 105.35 2.47 AFAD TVAN VMUR ??? IR c 94.33 2.50 AFAD VMUR ORDU ??? IR c 313.28 2.62 AFAD ORDU SURC ??? IR d 211.25 2.72 AFAD SURC CUALT ??? IR c 272.18 2.81 AFAD CUALT SARI BHZ KO -- - a 256.48 3.19 ISC SARI GNI S?Z IR D 73.26 3.50 MOS GNI ONI HHZ GO -- + a 33.76 4.09 ISC ONI TBLG HHZ GO -- - a 51.64 4.17 ISC TBLG TAHT BHZ KO -- + a 230.71 4.37 ISC TAHT NCK S?Z IR C 28.56 4.91 MOS NCK KIV S?Z IR C 19.39 5.04 MOS KIV SUDU S?Z IR C 326.53 6.93 MOS SUDU TESR ??? IR D 310.36 12.42 BUC TESR VOIR ??? IR D 303.67 12.92 BUC VOIR VOIR S?Z IR D 303.67 12.92 MOS VOIR BURAR ??? IR D 312.26 13.83 BUC BURAR BURAR S?Z IR D 312.26 13.83 MOS BURAR AKASG B?Z IR C 329.24 13.91 MOS AKASG KIEV S?Z IR C 329.19 13.91 MOS KIEV GZR ??? IR C 301.04 14.39 BUC GZR MDVR ??? IR C 297.85 14.93 BUC MDVR DRGR ??? IR D 306.11 14.95 BUC DRGR DRGR S?Z IR D 306.11 14.95 MOS DRGR OBN S?Z IR C 352.10 16.10 MOS OBN AB07 SHZ KZ -- - a 48.00 17.20 ISC AB07 KLNR S?Z IR D 325.13 20.54 MOS KLNR ARU B?Z IR D 28.95 20.99 MOS ARU KBA ??? IR c 300.59 21.15 VIE KBA VSU S?Z IR C 339.93 21.17 MOS VSU MOTA ??? IR c 300.51 22.70 VIE MOTA SOKR S?Z IR D 21.68 22.90 MOS SOKR AAK S?Z IR C 71.38 25.90 MOS AAK ULN S?Z IR C 56.69 47.73 MOS ULN TIXI S?Z IR C 23.41 52.86 MOS TIXI KLR S?Z IR D 47.69 62.40 MOS KLR SEY S?Z IR D 27.97 64.73 MOS SEY BILL S?Z IR C 19.54 65.66 MOS BILL sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
