Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta ERM S?Z IR D 14.19 4.42 MOS ERM YUK B?Z IR D 25.26 7.04 MOS YUK VLA S?Z IR D 308.77 9.22 MOS VLA TJN S?Z IR D 267.62 11.54 MOS TJN SNY ??? IR d 291.99 14.52 BJI SNY QZH ??? IR c 243.67 23.43 BJI QZH WHN ??? IR d 260.54 23.70 BJI WHN SEY S?Z IR C 11.12 26.06 MOS SEY ULN S?Z IR D 303.00 27.16 MOS ULN GYA ??? IR c 259.44 31.57 BJI GYA GTA ??? IR d 286.16 32.59 BJI GTA TIXI S?Z IR D 352.88 34.62 MOS TIXI KRAR S?Z IR D 315.53 37.12 MOS KRAR KTH BHZ AK -- - a 34.39 47.04 ISC KTH WRH BHZ AK -- + a 33.11 48.27 ISC WRH TARG HHZ KC -- - a 295.81 48.30 ISC TARG COLA S?Z IR C 32.57 48.36 MOS COLA TKM2 BHZ KN -- + a 297.97 49.50 ISC TKM2 USP BHZ KN -- + a 298.72 50.16 ISC USP AAK S?Z IR C 297.94 50.36 MOS AAK BAL BHZ AK -- + a 37.27 51.24 ISC BALM INK BHZ CN -- - a 27.36 53.66 ISC INK SOKR S?Z IR C 322.29 55.91 MOS SOKR ARU B?Z IR C 318.29 55.99 MOS ARU WB0 BHZ AU -- + a 188.16 57.60 ISC WB0 WRAB S?Z IR D 188.19 57.77 MOS WRAB WR0 BHZ AU -- + a 187.97 57.78 ISC WR0 APA M?Z IR C 335.66 62.15 MOS APA LLLB BHZ CN -- + a 44.05 65.59 ISC LLLB SUF HHZ HE -- + a 333.25 67.46 ISC SUF OBN S?Z IR D 323.16 67.67 MOS OBN OMAK BHZ UW -- + a 45.21 68.18 ISC B08A GOF S?Z IR D 311.70 69.80 MOS GOF VSU S?Z IR D 329.52 69.97 MOS VSU KIV S?Z IR D 310.88 70.62 MOS KIV NEY S?Z IR D 310.24 71.00 MOS NEY GNI S?Z IR C 306.64 71.47 MOS GNI AKH ??? IR C 308.30 71.56 BUC AKH AKH S?Z IR C 308.30 71.56 MOS AKH CMB BHZ BK 00 + a 54.75 73.28 ISC CMB FRB BHZ CN -- + a 13.35 76.04 ISC FRB BURAR ??? IR C 321.74 77.91 BUC BURAR BURAR S?Z IR C 321.74 77.91 MOS BURAR TESR ??? IR C 320.23 77.94 BUC TESR CFR ??? IR D 318.50 78.08 BUC CFR CFR S?Z IR D 318.50 78.08 MOS CFR VRI ??? IR C 319.70 78.34 BUC VRI VRI S?Z IR C 319.70 78.34 MOS VRI ARCR ??? IR C 321.76 78.70 BUC ARCR ISR ??? IR C 319.24 78.95 BUC ISR ISR S?Z IR C 319.24 78.95 MOS ISR MSAB ??? IR C 317.83 78.97 BUC MSAB VOIR ??? IR C 320.21 79.49 BUC VOIR VOIR S?Z IR C 320.21 79.49 MOS VOIR DRGR ??? IR C 322.35 79.70 BUC DRGR DRGR S?Z IR C 322.35 79.70 MOS DRGR ARR ??? IR C 320.37 79.75 BUC ARR LOT ??? IR C 320.86 80.13 BUC LOT CLL ??? IR + 330.23 80.61 CLL CLL CLL S?Z IR C 330.23 80.61 MOS CLL VRAC S?Z IR C 327.14 80.66 MOS VRAC GZR ??? IR C 321.32 80.66 BUC GZR GZR S?Z IR C 321.32 80.66 MOS GZR SCHF BHZ SX -- + a 330.13 81.34 ISC SCHF SUSD BHZ TA -- + a 39.15 81.55 ISC SUSD WERN HHZ SX -- + a 329.90 81.65 ISC WERN TRIB BHZ SX -- + a 330.06 81.70 ISC TRIB T25A BHZ TA -- + a 47.32 83.69 ISC T25A BGNE BHZ TA -- + a 40.84 84.14 ISC BGNE SCHQ BHZ CN -- + a 16.12 84.60 ISC SCHQ 121A BHZ TA -- + a 52.61 84.75 ISC 121A sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
