Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta ANWB ??? IR c 198.19 4.37 TRN ANWB SMRT ??? IR c 214.56 4.56 TRN SMRT SEUS ??? IR c 210.17 4.99 TRN SEUS SABA ??? IR c 213.38 5.01 TRN SABA SEG ??? IR c 191.54 5.53 TRN SEG SSG ??? IR c 192.55 5.87 TRN SSG DWS ??? IR c 188.41 6.31 TRN DWS SJG BHZ IU 10 + a 236.68 6.60 ISC SJG FDF ??? IR c 186.22 7.12 TRN FDF GRGR ??? IR c 187.53 9.74 TRN GRGR ANMO B?Z IR D 298.32 42.25 MOS ANMO RESF ??? IR C 52.31 54.18 STR RESF MELF ??? IR C 52.25 54.49 STR MELF VALF ??? IR C 52.86 55.41 STR VALF FILF ??? IR C 52.67 55.81 STR FILF SJAF ??? IR C 52.77 56.05 STR SJAF LBL ??? IR C 49.47 56.38 STR LBL THEF ??? IR C 46.00 58.37 STR THEF LOMF ??? IR C 47.04 58.92 STR LOMF ECH ??? IR C 46.04 59.15 STR ECH KONO S?Z IR D 32.95 61.28 MOS KONO APA S?Z IR D 23.82 71.44 MOS APA KIEV B?Z IR C 41.65 73.14 MOS KIEV OBN S?Z IR D 35.97 76.20 MOS OBN GOF S?Z IR C 43.91 83.77 MOS GOF NEY B?Z IR D 45.66 84.32 MOS NEY NCK S?Z IR C 45.17 84.79 MOS NCK TIXI S?Z IR D 357.08 86.53 MOS TIXI ARU B?Z IR D 29.15 86.67 MOS ARU GNI B?Z IR C 47.82 87.01 MOS GNI BRVK S?Z IR D 27.33 94.02 MOS BRVK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
