Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta NNA B?Z IR C 341.12 2.75 MOS NNA PB04 BHZ CX -- - a 145.32 9.44 ISC PB04 PB04 HHZ CX -- - a 145.32 9.44 ISC PB04 SAML BHZ IU 00 - a 67.14 13.69 ISC SAML CPUP SHZ GT 10 + a 126.76 20.94 ISC CPUP CPUP BHZ GT 00 + a 126.76 20.94 ISC CPUP CPUP SHZ GT 10 + a 126.76 20.94 ISC CPUP CPUP BHZ GT 00 + a 126.76 20.94 ISC CPUP UPD2 H?Z IR C 354.74 23.10 UCR UPD2 BCIP B?Z IR C 350.46 23.94 UCR BCIP HDC BHZ G 00 + a 341.19 25.76 ISC HDC PLCA SHZ GT 10 - a 170.79 26.45 ISC PLCA EFI B?Z IR C 162.58 39.66 MOS EFI TUL1 BHZ TA -- + a 339.97 53.65 ISC TUL1 MGMO BHZ NM -- - a 343.82 53.74 ISC MGMO 121A BHZ TA -- + a 327.43 55.91 ISC 121A ANMO B?Z IR C 330.23 57.17 MOS ANMO 214A BHZ TA -- + a 323.13 58.25 ISC 214A W18A BHZ TA -- - a 327.83 58.94 ISC W18A Q24A BHZ TA -- - a 333.90 59.89 ISC Q24A SHP HHZ NN -- + a 325.08 62.88 ISC SHPR DUG BHZ US 00 + a 329.35 64.41 ISC DUG MPP BHZ CI -- - a 320.84 64.48 ISC PKM PAH HHZ NN -- + a 324.95 67.50 ISC PAHR HLID BHZ US 00 + a 330.74 67.74 ISC HLID SNAA BHZ GE -- + a 161.32 70.92 ISC SNAA DBIC BHZ GT 00 + a 78.42 73.56 ISC DBIC DBIC BHZ GT 00 + a 78.42 73.56 ISC DBIC QSPA BHZ IU 00 + a 180.05 75.54 ISC QSPA QSPA BHZ IU 80 + a 180.05 75.54 ISC QSPA QSPA BHZ IU 10 + a 180.05 75.54 ISC QSPA VNDA BHZ GT 00 + a 190.70 82.39 ISC VNDA COI BHZ SS -- + a 45.48 82.97 ISC COI TAM BHZ G 00 + a 65.95 87.93 ISC TAM SUMG ??? IR C 10.56 90.43 DNK SUMG SUMG S?Z IR C 10.56 90.43 MOS SUMG sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
