Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CET2 HHZ IV -- + a 321.14 0.23 ISC CET2 SERS BHZ IV -- + a 126.22 0.53 ISC SERS SERS HHZ IV -- + a 126.22 0.53 ISC SERS PIPA BHZ IV -- + a 75.37 0.54 ISC PIPA PIPA HHZ IV -- + a 75.37 0.54 ISC PIPA MMN HHZ IV -- + a 347.94 0.55 ISC MMN GRI EHZ IV -- - a 157.49 0.57 ISC GRI CUC BHZ MN -- + a 338.79 0.69 ISC CUC JOPP BHZ IV -- + a 195.05 0.77 ISC JOPP SLCN BHZ IV -- - a 339.55 1.11 ISC SLCN SLCN HHZ IV -- - a 339.55 1.11 ISC SLCN CMPR HHZ IV -- - a 326.56 1.16 ISC CMPR CMPR BHZ IV -- + a 326.56 1.16 ISC CMPR MSRU BHZ IV -- + a 204.67 1.19 ISC MSRU MSRU HHZ IV -- + a 204.67 1.19 ISC MSRU SOI EHZ IV -- - a 183.05 1.28 ISC SOI MPNC HHZ IV -- + a 207.37 1.35 ISC MPNC MPAZ HHZ IV -- + a 184.33 1.40 ISC MPAZ MRLC HHZ IV -- + a 340.61 1.49 ISC MRLC NOCI BHZ IV -- + a 25.98 1.60 ISC NOCI NOCI HHZ IV -- + a 25.98 1.60 ISC NOCI SSY HHZ IV -- - a 201.32 2.34 ISC SSY HAVL HHZ IV -- - a 198.90 2.52 ISC HAVL sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
