Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta TOK ??? IR D 29.00 0.15 JMA TOK JYO ??? IR C 180.29 0.33 JMA JYO JOD2 ??? IR C 238.75 0.55 JMA JOD2 TSK BHZ PS -- - a 28.55 0.75 ISC TSK JRY ??? IR D 306.86 0.78 JMA JRY JIM2 ??? IR C 193.14 0.86 JMA JIM2 JAG ??? IR D 348.79 0.89 JMA JAG JYN ??? IR C 266.89 0.92 JMA JYN BSO3 ??? IR D 137.10 1.02 JMA BSO3 JIZS ??? IR C 218.05 1.05 JMA JIZS INU BHZ G 00 + a 265.40 2.16 ISC INU SEY B?Z IR C 12.17 28.52 MOS SEY TIXI B?Z IR C 354.29 36.60 MOS TIXI CMAR B?Z IR C 255.53 39.76 MOS CMAR MKAR B?Z IR C 303.16 43.73 MOS MKAR KUR21 BHZ KZ -- + a 308.93 45.82 ISC KUR21 KDAK B?Z IR C 40.96 49.14 MOS KDAK WB0 BHZ AU -- - a 186.05 55.24 ISC WB0 WRAB B?Z IR C 186.08 55.41 MOS WRAB WRA B?Z IR C 186.09 55.42 MOS WRA WC4 BHZ AU -- - a 186.09 55.44 ISC WC4 FINES B?Z IR C 331.95 69.46 MOS FINES AKASG B?Z IR C 321.82 74.59 MOS AKASG sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
