Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta HOPE BHZ II 10 + a 284.94 4.83 ISC HOPE HOPE BHZ II 00 + a 284.94 4.83 ISC HOPE VNA3 BHZ AW -- + a 159.65 17.49 ISC VNA3 VNAC6 SHZ AW -- + a 157.11 17.71 ISC VNA2 VNAB5 SHZ AW -- + a 157.09 17.71 ISC VNA2 VNAC1 SHZ AW -- + a 157.06 17.71 ISC VNA2 VNAA1 SHZ AW -- + a 157.09 17.72 ISC VNA2 VNAB1 SHZ AW -- + a 157.08 17.72 ISC VNA2 VNAA3 SHZ AW -- + a 157.09 17.72 ISC VNA2 VNAA2 SHZ AW -- + a 157.09 17.72 ISC VNA2 VNAB3 SHZ AW -- + a 157.09 17.72 ISC VNA2 VNAB2 SHZ AW -- + a 157.08 17.72 ISC VNA2 VNAC4 SHZ AW -- + a 157.11 17.72 ISC VNA2 VNAC3 SHZ AW -- + a 157.08 17.73 ISC VNA2 EFI S?Z IR C 270.95 17.89 MOS EFI SNAA BHZ GE -- + a 155.47 19.29 ISC SNAA NVL S?Z IR C 146.52 22.89 MOS NVL TRQA BHZ IU 10 - a 294.32 28.54 ISC TRQA TRQA HHZ IU 10 - a 294.32 28.54 ISC TRQA QSPA BHZ IU 80 + a 179.98 34.46 ISC QSPA QSPA BHZ IU 10 + a 179.98 34.46 ISC QSPA QSPA BHZ IU 00 + a 179.98 34.46 ISC QSPA QSPA BHZ IU 70 + a 179.98 34.46 ISC QSPA QSPA HHZ IU 85 + a 179.98 34.46 ISC QSPA MAW BHZ AU -- + a 144.10 40.80 ISC MAW GO03 BHZ C -- - a 295.87 41.03 ISC GO03 BOSA BHZ GT 00 + a 77.31 46.63 ISC BOSA VNDA BHZ GT 00 + a 183.08 46.80 ISC VNDA LPAZ BHZ GT 00 - a 306.50 49.62 ISC LPAZ LBTB BHZ GT 00 + a 74.68 49.65 ISC LBTB TSUM BHZ IU 00 + a 62.39 50.22 ISC TSUM MIR S?Z IR C 153.71 50.35 MOS MIR SAML HHZ IU 10 - a 316.06 54.09 ISC SAML CASY BHZ IU 10 + a 160.97 54.40 ISC CASY CASY BHZ IU 00 + a 160.97 54.40 ISC CASY LSZ BHZ IU 10 + a 70.27 58.98 ISC LSZ LSZ BHZ IU 00 + a 70.27 58.98 ISC LSZ sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
