Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta APE B?Z IR D 304.19 1.22 MOS APE TURN ??? IR c 71.09 1.53 AFAD TURN AYDN ??? IR d 34.07 1.54 AFAD AYDN DALY ??? IR c 73.50 1.56 AFAD DALY URLA ??? IR d 355.50 1.97 AFAD URLA TAVA ??? IR c 57.04 2.01 AFAD TAVA DNZL ??? IR c 53.56 2.22 AFAD DNZL AKAS ??? IR c 93.08 2.28 AFAD AKAS GOLH ??? IR c 68.31 2.38 AFAD GOLH BRDR ??? IR c 62.50 2.92 AFAD BRDR KORT ??? IR c 76.88 2.92 AFAD KORT DEMI ??? IR d 29.34 3.06 AFAD DEMI ISP B?Z IR C 63.24 3.31 MOS ISP ULC ??? IR D 315.83 8.08 PDG ULC ULC ??? IR D 315.83 8.08 CSEM ULC PVY ??? IR D 321.65 8.14 PDG PVY PVY ??? IR D 321.65 8.14 CSEM PVY DRME ??? IR C 316.79 8.26 PDG DRME DRME ??? IR C 316.79 8.26 CSEM DRME PDG ??? IR C 318.27 8.39 CSEM PDG TTG ??? IR C 318.27 8.39 PDG TTG BUM ??? IR D 316.39 8.50 PDG BUM BUM ??? IR D 316.39 8.50 CSEM BUM TAR1 ??Z IR C 301.85 8.53 OSUB TAR1 KOME ??? IR C 321.21 8.55 PDG KOME KOME ??? IR C 321.21 8.55 CSEM KOME CEME ??? IR C 317.69 8.65 PDG CEME CEME ??? IR C 317.69 8.65 CSEM CEME MASS ??Z IR C 302.18 8.67 OSUB MASS NKME ??? IR C 318.87 8.78 PDG NKME NKME ??? IR C 318.87 8.78 CSEM NKME NKY ??? IR C 319.22 8.79 PDG NKY NKY ??? IR C 319.22 8.79 CSEM NKY HCY ??? IR D 315.83 8.82 PDG HCY HCY ??? IR D 315.83 8.82 CSEM HCY TREB ??? IR D 316.69 9.08 CSEM TREB BRY ??? IR D 318.15 9.10 PDG BRY BRY ??? IR D 318.15 9.10 CSEM BRY BBLS ??? IR C 325.14 9.37 CSEM BBLS CRES ??? IR C 321.35 12.71 CSEM CRES KIEV S?Z IR D 6.18 14.41 MOS KIEV KLNR B?Z IR C 348.04 18.78 MOS KLNR MEM SHZ IR c 320.06 20.62 UCC MEM VSU S?Z IR D 359.92 22.09 MOS VSU KONO S?Z IR C 339.82 25.80 MOS KONO BRVK S?Z IR C 47.20 34.48 MOS BRVK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
