Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta EOS1 ??? IR C 349.83 0.19 TAP EOS1 TWC ??? IR C 310.25 0.38 TAP TWC NANB ??? IR C 279.38 0.38 TAP NANB ENA ??? IR C 279.26 0.39 TAP ENA ILA ??? IR C 316.50 0.55 TAP ILA NACB ??? IR C 249.98 0.55 TAP NACB TWD ??? IR C 241.42 0.59 TAP TWD ENTT ??? IR C 296.76 0.61 TAP ENTT SLBB ??? IR C 308.87 0.62 TAP SLBB ENLB ??? IR C 228.31 0.69 TAP ENLB NNSB ??? IR C 275.19 0.71 TAP NNSB NNS ??? IR C 276.04 0.72 TAP NNS YOJ ??? IR D 82.74 0.78 TAP YOJ YOJ BHZ JP -- - a 82.35 0.78 ISC YOJ YHNB ??? IR C 293.03 0.78 TAP YHNB NSK ??? IR C 293.00 0.80 TAP NSK WHF ??? IR C 255.22 0.85 TAP WHF TATO HHZ IU 10 - a 315.06 0.86 ISC TATO ESL ??? IR C 230.76 0.86 TAP ESL TWT ??? IR C 263.15 0.91 TAP TWT TDCB ??? IR C 263.26 0.93 TAP TDCB CHGB ??? IR C 251.63 0.95 TAP CHGB YM11 ??? IR D 326.16 0.96 TAP YM11 TWS1 ??? IR C 317.31 1.00 TAP TWS1 HGSD ??? IR C 218.09 1.10 TAP HGSD EHY ??? IR C 222.19 1.15 TAP EHY SSLB ??? IR C 242.77 1.25 TAP SSLB YULB ??? IR C 219.51 1.25 TAP YULB TWF1 ??? IR C 218.39 1.28 TAP TWF1 CHKT ??? IR C 210.32 1.46 TAP CHKT STYT ??? IR C 227.42 1.76 TAP STYT TWK ??? IR D 234.88 1.89 TAP TWK MATB ??? IR D 311.98 2.68 TAP MATB QZH ??? IR d 280.77 3.30 BJI QZH sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
