Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PB15 H?Z IR C 277.45 0.54 GUC PB15 PB06 HHZ CX -- - a 312.12 0.85 ISC PB06 PB05 H?Z IR C 289.11 1.28 GUC PB05 PB03 HHZ CX -- - a 326.78 1.46 ISC PB03 PB04 H?Z IR C 308.77 1.50 GUC PB04 PB09 H?Z IR D 347.49 1.51 GUC PB09 PB10 H?Z IR C 261.02 1.55 GUC PB10 PB07 H?Z IR C 329.00 1.80 GUC PB07 PB14 H?Z IR C 225.64 1.93 GUC PB14 PB02 HHZ CX -- + a 334.27 2.16 ISC PB02 PB02 BHZ CX -- + a 334.27 2.16 ISC PB02 PB01 BHZ CX -- + a 345.91 2.29 ISC PB01 PB01 HHZ CX -- + a 345.91 2.29 ISC PB01 PATCX HHZ CX -- - a 334.17 2.71 ISC PATCX PB08 BHZ CX -- + a 355.46 3.13 ISC PB08 LPAZ SHZ GT 10 + a 6.00 6.99 ISC LPAZ LPAZ BHZ GT 00 + a 6.00 6.99 ISC LPAZ PTGA BHZ IU 10 + a 22.39 24.03 ISC PTGA SNAA BHZ GE -- - a 160.62 60.60 ISC SNAA QSPA BHZ IU 00 - a 180.04 66.92 ISC QSPA QSPA BHZ IU 80 - a 180.04 66.92 ISC QSPA QSPA HHZ IU 85 - a 180.04 66.92 ISC QSPA QSPA BHZ IU 10 - a 180.04 66.92 ISC QSPA ANMO S?Z IR D 327.30 68.00 MOS ANMO U15A BHZ AE -- - a 324.40 72.15 ISC U15A GMR BHZ CI -- - a 321.12 72.83 ISC GMRC HLID BHZ US 00 - a 328.05 78.55 ISC HLID sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
