Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PINNC BHZ ND 00 + a 191.79 3.43 ISC PINNC KOUNC BHZ ND 00 + a 249.92 3.91 ISC KOUNC STKA BHZ AU -- + a 237.01 27.02 ISC STKA WHYH SHZ AU 00 + a 237.20 30.61 ISC WHYH BBOO BHZ AU -- - a 238.38 31.75 ISC BBOO AS18 SHZ AU -- - a 255.94 32.11 ISC AS18 AS06 SHZ AU -- - a 256.02 32.12 ISC AS06 AS07 SHZ AU -- - a 255.98 32.12 ISC AS07 AS08 SHZ AU -- - a 255.96 32.13 ISC AS08 AS05 SHZ AU -- - a 256.02 32.14 ISC AS05 AS09 SHZ AU -- - a 255.92 32.14 ISC AS09 AS02 SHZ AU -- - a 255.96 32.15 ISC AS02 AS16 SHZ AU -- - a 256.04 32.15 ISC AS16 AS10 SHZ AU -- - a 255.93 32.17 ISC AS10 AS15 SHZ AU -- - a 256.04 32.17 ISC AS15 AS14 SHZ AU -- - a 256.01 32.17 ISC AS14 AS31 BHZ AU -- - a 255.99 32.18 ISC AS31 AS11 SHZ AU -- - a 255.96 32.18 ISC AS11 AS13 SHZ AU -- - a 256.01 32.19 ISC AS13 FITZ BHZ AU -- - a 264.47 40.27 ISC FITZ KMBL BHZ AU -- + a 244.44 43.30 ISC KMBL MEEK BHZ AU -- - a 251.26 46.03 ISC MEEK KLBR SHZ AU -- + a 244.45 46.83 ISC KLBR RKGY SHZ AU -- + a 240.42 47.68 ISC RKGY NV07 SHZ IM -- - a 48.88 89.54 ISC NV07 NV03 SHZ IM -- - a 48.86 89.54 ISC NV03 NV05 SHZ IM -- - a 48.84 89.55 ISC NV05 NV06 SHZ IM -- + a 48.87 89.56 ISC NV06 NV11 SHZ IM -- - a 48.90 89.65 ISC NV11 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
