Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta NV11 SHZ IM -- - a 342.53 0.43 ISC NV11 NV06 SHZ IM -- - a 330.81 0.46 ISC NV06 NV04 SHZ IM -- + a 328.14 0.47 ISC NV04 NV05 SHZ IM -- + a 330.79 0.49 ISC NV05 NV10 SHZ IM -- + a 328.69 0.50 ISC NV10 RYN HHZ NN -- + a 325.47 0.74 ISC RYN MLAC BHZ CI -- - a 240.18 0.78 ISC MLAC TIN BHZ CI -- - a 191.37 0.98 ISC TIN CWC BHZ CI -- - a 182.71 1.58 ISC CWC CMB BHZ BK 00 - a 271.18 1.89 ISC CMB R11A BHZ TA -- + a 79.42 1.92 ISC R11A VOG BHZ CI -- - a 213.72 2.03 ISC VOG PRN HHZ NN -- + a 103.83 2.41 ISC PRN GSC BHZ CI -- + a 160.34 2.87 ISC GSC WTNK HHZ NN -- + a 126.57 3.00 ISC WTNK SAO BHZ BK 00 - a 246.59 3.03 ISC SAO DJJ BHZ CI -- + a 185.68 3.92 ISC DJJ FMP BHZ CI -- - a 183.40 4.30 ISC FMP WDC BHZ BK 00 + a 307.31 4.36 ISC WDC N02D BHZ TA -- + a 310.42 4.69 ISC N02D M02C BHZ TA -- - a 313.43 5.04 ISC M02C K04D BHZ TA -- + a 329.15 5.42 ISC K04D J05D BHZ TA -- - a 335.88 5.81 ISC J05D J04D BHZ TA -- + a 330.29 6.08 ISC J04D I04A BHZ TA -- + a 331.26 6.67 ISC I04A I05D BHZ TA -- + a 339.25 6.80 ISC I05D G05D BHZ TA -- - a 342.01 7.63 ISC G05D sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
