Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PAX BHZ AK -- - a 10.05 0.75 ISC PAX DHY BHZ AK -- + a 319.14 1.13 ISC DHY SAW BHZ AK -- + a 251.65 1.29 ISC SML VRDI BHZ AK -- + a 131.69 1.49 ISC VRDI GLI BHZ AK -- - a 205.82 1.50 ISC GLI DOT BHZ AK -- - a 27.78 1.61 ISC DOT EYAK BHZ AK -- - a 179.90 1.69 ISC EYAK PMR BHZ AT -- - a 249.49 1.72 ISC PMR RND BHZ AK -- + a 310.87 1.85 ISC RND HIN BHZ AK -- - a 191.38 1.88 ISC HIN BAL BHZ AK -- + a 124.96 2.02 ISC BALM HMT BHZ AK -- - a 158.62 2.04 ISC HMT KIAG BHZ AK -- + a 127.53 2.09 ISC KIAG KHIT BHZ AK -- - a 145.02 2.17 ISC KHIT GRIN BHZ AK -- - a 147.97 2.29 ISC GRIN KULT BHZ AK -- - a 142.34 2.48 ISC KULT WRH BHZ AK -- + a 335.91 2.48 ISC WRH TCOL BHZ TA -- + a 341.35 2.81 ISC TCOL MID BHZ AT -- - a 186.04 2.83 ISC MID PIC1 HHZ YE 01 + a 346.26 2.99 ISC POKR EGAK BHZ US 00 - a 36.90 3.28 ISC EGAK PPD BHZ AK -- - a 1.68 3.30 ISC PRP RSO EHZ AV -- - a 245.28 3.81 ISC RSO PNL BHZ AK -- - a 126.94 4.03 ISC PNL FYU BHZ AK -- - a 2.75 4.36 ISC FYU LZH ??? IR c 304.62 67.30 BJI LZH DAV ??? IR d 272.13 83.17 QCP DAV sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
