Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta NIL BHZ II 10 - a 150.98 3.23 ISC NIL NIL BHZ II 00 - a 150.98 3.23 ISC NIL BTK BHZ KR -- - a 353.01 3.58 ISC BTK AAK ??? IR c 20.42 6.58 NNC AAK KK31 ??? IR d 354.43 6.63 NNC KK31 KKAR BHZ KZ -- - a 354.43 6.63 ISC KKAR TKM2 ??? IR d 25.54 7.18 NNC TKM2 PDGK ??? IR c 39.89 9.23 NNC PDGK OTUK ??? IR d 3.12 11.76 NNC OTUK KURBB ??? IR c 17.79 15.02 NNC KURBB KURK S?Z IR C 17.86 15.13 MOS KURK AB31 ??? IR d 330.35 15.24 NNC AB31 ABKAR BHZ KZ -- - a 330.35 15.24 ISC ABKAR BRVK ??? IR c 357.66 16.57 NNC BRVK BRVK S?Z IR C 357.66 16.57 MOS BRVK DGZ B?Z IR C 36.42 17.59 MOS DGZ GNI B?Z IR D 288.01 21.19 MOS GNI ARU B?Z IR D 340.55 21.73 MOS ARU NCK S?Z IR D 296.79 22.34 MOS NCK NEY S?Z IR C 295.93 22.94 MOS NEY LZH ??? IR d 81.15 26.10 BJI LZH TLY S?Z IR C 46.20 27.41 MOS TLY AKASG B?Z IR C 308.76 33.19 MOS AKASG JOF HHZ HE -- - a 329.93 36.02 ISC JOF JOF BHZ HE -- - a 329.93 36.02 ISC JOF VSU S?Z IR D 321.48 36.38 MOS VSU SUF HHZ HE -- + a 327.97 38.09 ISC SUF NC303 BHZ NO 00 + a 323.28 44.51 ISC NC303 NB201 BHZ NO 00 + a 323.03 44.53 ISC NB201 NC204 BHZ NO 00 + a 323.32 44.81 ISC NC204 KLR S?Z IR C 53.84 44.89 MOS KLR sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
