Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta JEM ??? IR C 29.34 0.51 JMA JEM JNBK ??? IR C 355.63 0.71 JMA JNBK JTHR ??? IR C 26.14 0.80 JMA JTHR JSHD ??? IR C 342.35 0.88 JMA JSHD JCH ??? IR C 20.89 1.11 JMA JCH JBT2 ??? IR C 344.23 1.25 JMA JBT2 JKB ??? IR D 283.68 1.38 JMA JKB JOB ??? IR C 29.13 1.52 JMA JOB JTM ??? IR C 239.86 1.54 JMA JTM JANG ??? IR C 219.99 1.56 JMA JANG JNB ??? IR D 304.43 1.60 JMA JNB JAR ??? IR C 21.80 1.86 JMA JAR JYM2 ??? IR D 287.25 1.91 JMA JYM2 NMR B?Z IR D 49.18 2.80 MOS NMR GRPR S?Z IR C 40.94 3.25 MOS GRPR LAGR S?Z IR C 40.32 3.30 MOS LAGR YUK M?Z IR C 41.26 3.32 MOS YUK KUR B?Z IR D 43.44 5.18 MOS KUR TEY S?Z IR C 309.39 5.71 MOS TEY WHN ??? IR d 253.48 25.41 BJI WHN MKAR BHZ KZ -- - a 298.27 42.78 ISC MKAR KURK BHZ II 00 - a 304.70 44.12 ISC KURK KURK BHZ II 10 - a 304.70 44.12 ISC KURK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
