Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta IMMV HHZ HL -- - a 82.56 0.75 ISC IMMV IMMV SHZ GE -- - a 82.61 0.75 ISC IMMV IMMV HHZ GE -- - a 82.61 0.75 ISC IMMV KTHA HHZ GE -- - a 359.41 0.89 ISC KTHA KTHA BHZ GE -- - a 359.41 0.89 ISC KTHA GVD BHZ HL -- - a 122.06 0.98 ISC GVD ZKR SHZ GE -- - a 94.68 2.58 ISC ZKR APE B?Z IR C 48.76 2.61 MOS APE APE SHZ HL -- + a 48.76 2.61 ISC APE ARG SHZ HL -- + a 76.91 4.19 ISC ARG ARG HHZ HL -- + a 76.91 4.19 ISC ARG ARG BHZ HL -- + a 76.88 4.19 ISC ARG SIGR HHZ HT -- - a 29.20 4.43 ISC SIGR GRG BHZ HT -- + a 354.79 5.61 ISC GRG PUK HHZ AC -- - a 340.50 7.11 ISC PUK BCI HHZ AC -- + a 342.37 7.37 ISC BCI BBLS BHZ SJ -- - a 342.69 8.95 ISC BBLS BRTR B?Z IR C 59.47 9.45 MOS BRTR AMAZ SHZ IS -- - a 107.79 10.61 ISC AMAZ EIL SHZ GE -- - a 116.23 11.52 ISC EIL KHC S?Z IR D 335.96 15.43 MOS KHC VSR S?Z IR D 31.26 19.63 MOS VSR OBN S?Z IR C 21.12 21.84 MOS OBN BRVK S?Z IR C 46.84 37.39 MOS BRVK AAK S?Z IR D 63.59 40.09 MOS AAK KURK B?Z IR C 51.06 42.38 MOS KURK MKAR B?Z IR C 56.46 45.08 MOS MKAR MKAR BHZ KZ -- - a 56.47 45.09 ISC MKAR TIXI S?Z IR D 20.28 61.57 MOS TIXI YSS S?Z IR D 36.96 81.80 MOS YSS sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
