Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta SLA H?Z IR D 113.81 1.59 GUC SLA LVC BHZ IU 00 + a 311.07 2.21 ISC LVC LVC BHZ IU 10 + a 311.07 2.21 ISC LVC LVC HHZ IU 10 + a 311.07 2.21 ISC LVC LVC H?2 IR D 311.14 2.21 GUC LVC LVC B?Z IR U 311.14 2.21 SJA LVC PB15 H?Z IR C 291.42 2.34 GUC PB15 PB15 HHZ CX -- + a 291.42 2.34 ISC PB15 GO02 B?Z IR C 244.10 2.50 GUC GO02 GO02 BHZ C -- + a 244.10 2.50 ISC GO02 PB06 H?Z IR C 300.70 2.65 GUC PB06 PB06 HHZ CX -- + a 300.70 2.65 ISC PB06 PB09 H?Z IR C 318.72 3.01 GUC PB09 PB05 HHZ CX -- + a 292.70 3.10 ISC PB05 PB10 HHZ CX -- + a 279.50 3.21 ISC PB10 PB04 HHZ CX -- + a 301.29 3.30 ISC PB04 PB07 H?Z IR C 311.92 3.48 GUC PB07 PB07 HHZ CX -- + a 311.92 3.48 ISC PB07 PB01 HHZ CX -- - a 323.50 3.74 ISC PB01 PB02 HHZ CX -- + a 316.33 3.77 ISC PB02 PB11 HHZ CX -- + a 330.68 4.91 ISC PB11 PSGCX HHZ CX -- + a 327.30 5.27 ISC PSGCX MNMCX BHZ CX -- + a 334.35 5.45 ISC MNMC PB12 HHZ CX -- + a 330.50 6.22 ISC PB12 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
