Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CYA H?Z IR D 122.70 1.17 GUC CYA VCA H?Z IR C 230.71 1.46 GUC VCA AHML H?Z IR C 54.33 1.74 GUC AHML GO03 B?Z IR C 273.49 2.95 GUC GO03 GO03 BHZ C -- + a 273.49 2.95 ISC GO03 SLA H?Z IR C 22.70 3.33 GUC SLA GO02 B?Z IR C 317.18 3.56 GUC GO02 GO02 BHZ C -- + a 317.18 3.56 ISC GO02 AZAP E?Z IR U 25.39 3.94 SJA AZAP GO04 B?Z IR U 234.42 4.13 SJA GO04 GO04 BHZ C -- + a 234.42 4.13 ISC GO04 RTCV E?Z IR U 198.87 4.27 SJA RTCV ASTB E?Z IR U 30.52 4.44 SJA ASTB MRA E?Z IR D 167.53 4.71 SJA MRA HJA E?Z IR U 16.88 4.78 SJA HJA PB10 H?Z IR U 321.73 5.39 SJA PB10 PB10 HHZ CX -- + a 321.73 5.39 ISC PB10 LVC BHZ IU 10 + a 340.34 5.48 ISC LVC PB05 HHZ CX -- + a 328.24 5.76 ISC PB05 PB03 HHZ CX -- - a 335.23 6.29 ISC PB03 PB03 BHZ CX -- - a 335.23 6.29 ISC PB03 PB01 HHZ CX -- - a 340.29 7.13 ISC PB01 CPUP BHZ GT 00 - a 82.39 8.67 ISC CPUP CPUP SHZ GT 10 + a 82.39 8.67 ISC CPUP QSPA BHZ IU 00 - a 180.04 62.41 ISC QSPA QSPA BHZ IU 10 - a 180.04 62.41 ISC QSPA QSPA BHZ IU 60 - a 180.04 62.41 ISC QSPA QSPA BHZ IU 70 - a 180.04 62.41 ISC QSPA QSPA BHZ IU 80 - a 180.04 62.41 ISC QSPA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
