Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta AGG HHZ HT -- + a 20.73 0.74 ISC AGG ITM HHZ HL -- + a 182.99 1.15 ISC ITM XOR BHZ HT -- + a 41.60 1.39 ISC XOR GRG BHZ HT -- + a 6.63 2.64 ISC GRG GRG HHZ HT -- + a 6.60 2.64 ISC GRG APE S?Z IR C 113.13 3.07 MOS APE APE ??? IR d 113.13 3.07 BUC APE TIR ??? IR d 332.06 3.43 BUC TIR PHP HHZ AC -- - a 340.82 3.56 ISC PHP TIP ??? IR d 283.31 4.18 BUC TIP TIP BHZ MN -- - a 283.32 4.18 ISC TIP VTS ??? IR d 12.00 4.39 BUC VTS PDG ??? IR d 333.76 4.60 BUC PDG PLVB ??? IR c 20.63 5.43 BUC PLVB ELND ??? IR c 31.46 5.46 BUC ELND HERR ??? IR d 2.59 6.55 BUC HERR BZS ??? IR d 357.88 7.29 BUC BZS ARR ??? IR c 14.76 7.30 BUC ARR BLY ??? IR c 332.15 7.36 BUC BLY VOIR ??? IR d 16.77 7.46 BUC VOIR MLR ??? IR c 21.07 7.74 BUC MLR PLOR ??? IR d 23.19 8.27 BUC PLOR VRI ??? IR c 23.48 8.31 BUC VRI BURAR ??? IR c 13.19 9.57 BUC BURAR PSZ ??? IR c 351.57 9.71 BUC PSZ VSU S?Z IR C 7.16 20.38 MOS VSU AAK S?Z IR D 66.60 39.63 MOS AAK KURK S?Z IR D 53.62 41.25 MOS KURK MKAR BHZ KZ -- - a 58.82 44.23 ISC MKAR sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
