Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PSGC H?Z IR D 63.89 0.77 GUC PSGC TA01 H?Z IR D 134.90 0.89 GUC TA01 PATCX H?Z IR C 143.40 1.10 GUC PATCX PB11 H?Z IR D 81.35 1.14 GUC PB11 PB12 H?Z IR C 20.68 1.41 GUC PB12 GO01 B?Z IR C 80.56 1.58 GUC GO01 PB08 H?Z IR C 97.53 1.61 GUC PB08 PB02 H?Z IR C 147.11 1.64 GUC PB02 PB01 H?Z IR C 130.94 1.69 GUC PB01 PB07 H?Z IR C 153.27 2.00 GUC PB07 PB16 H?Z IR C 38.79 2.04 GUC PB16 PB03 H?Z IR C 154.15 2.34 GUC PB03 PB06 H?Z IR C 156.81 3.00 GUC PB06 LVC BHZ IU 00 + a 146.13 3.22 ISC LVC PB10 BHZ CX -- + a 175.61 3.57 ISC PB10 PB14 HHZ CX -- + a 175.00 4.69 ISC PB14 NNA S?Z IR C 323.04 9.78 MOS NNA SAML BHZ IU 10 + a 35.26 13.20 ISC SAML PTGA BHZ IU 10 - a 30.47 21.86 ISC PTGA EFI S?Z IR C 165.43 33.23 MOS EFI RCBR BHZ IU 10 + a 72.33 36.74 ISC RCBR L55A BHZ TA -- - a 353.63 62.20 ISC L55A WVNY HHZ LD -- - a 353.53 62.44 ISC WVNY ANMO S?Z IR C 327.91 64.21 MOS ANMO SNAA B?Z IR C 161.01 64.34 MOS SNAA PFO S?Z IR C 320.22 68.75 MOS PFO QSPA BHZ IU 10 + a 180.04 70.25 ISC QSPA QSPA BHZ IU 70 + a 180.04 70.25 ISC QSPA PAB BHZ IU 10 + a 45.33 85.69 ISC PAB YKW3 BHZ CN -- + a 341.31 89.18 ISC YKW3 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
