Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CASC H?Z IR D 15.03 1.69 RSNC CASC PUAC H?Z IR D 30.62 2.37 RSNC PUAC GCUF H?Z IR D 9.04 2.74 RSNC GCUF BBAC H?Z IR C 8.60 3.54 RSNC BBAC GARC H?Z IR C 31.93 4.32 RSNC GARC BETC S?Z IR C 29.32 4.77 RSNC BETC MACC H?Z IR C 47.32 5.34 RSNC MACC GUVC S?Z IR C 52.02 6.53 RSNC GUVC BCIP BHZ CU 00 - a 349.07 10.79 ISC BCIP SDV BHZ IU 10 + a 34.48 12.53 ISC SDV SAML BHZ IU 00 + a 117.50 16.30 ISC SAML SAML BHZ IU 10 + a 117.50 16.30 ISC SAML LPAZ BHZ GT 00 + a 147.64 17.50 ISC LPAZ U56A BHZ TA -- + a 356.56 37.73 ISC U56A U57A BHZ TA -- + a 357.94 37.77 ISC U57A T58A BHZ TA -- - a 359.02 38.26 ISC T58A T57A BHZ TA -- + a 358.09 38.33 ISC T57A T56A BHZ TA -- + a 357.09 38.39 ISC T56A T47A BHZ N4 -- - a 348.16 39.26 ISC T47A T47A HHZ N4 -- - a 348.16 39.26 ISC T47A R54A BHZ TA -- + a 356.02 39.60 ISC R54A R58A BHZ TA -- + a 359.72 39.60 ISC R58A R57A BHZ TA -- + a 359.08 39.61 ISC R57A R55A BHZ TA -- + a 357.11 39.65 ISC R55A U40A BHZ TA -- + a 341.01 40.20 ISC U40A T42B HHZ N4 -- + a 343.44 40.28 ISC T42A T42B BHZ N4 -- + a 343.44 40.28 ISC T42A Q54A BHZ TA -- - a 356.32 40.38 ISC Q54A S44A HHZ N4 -- - a 345.91 40.42 ISC S44A SIUC BHZ NM 00 - a 345.96 40.43 ISC SIUC SIUC HHZ NM 00 - a 345.96 40.43 ISC SIUC MGMO BHZ NM -- + a 342.16 40.74 ISC MGMO MGMO HHZ NM -- - a 342.16 40.74 ISC MGMO Q44B BHZ N4 -- - a 346.73 41.52 ISC Q44A MNTX BHZ US 00 + a 323.94 42.14 ISC MNTX MSTX BHZ TA -- - a 328.61 42.40 ISC MSTX K54A BHZ TA -- + a 359.03 43.92 ISC K54A CCNY BHZ LD -- - a 358.86 44.24 ISC CCNY ANMO BHZ IU 00 - a 326.19 45.12 ISC ANMO WLVO HHZ WU -- + a 359.37 45.23 ISC WLVO CLWO HHZ WU -- + a 357.48 45.80 ISC CLWO SADO BHZ CN -- + a 358.65 46.08 ISC SADO ECSD BHZ US 00 - a 341.67 48.10 ISC ECSD ECSD BHZ US 10 - a 341.67 48.10 ISC ECSD TCU HHZ UU 01 + a 328.06 52.28 ISC TCUT HWUT BHZ US 00 - a 328.38 52.71 ISC HWUT SPU HHZ UU 01 + a 327.53 52.97 ISC SPUT MFID BHZ IW 00 + a 327.30 56.23 ISC MFID SCHQ BHZ CN -- + a 7.54 56.86 ISC SCHQ O03E HHZ TA -- + a 321.08 57.79 ISC O03E O03E BHZ TA -- + a 321.08 57.79 ISC O03E WDC HHZ BK 00 - a 320.98 58.42 ISC WDC DBIC BHZ GT 00 + a 82.62 73.22 ISC DBIC KULLO ??? IR C 5.53 76.98 DNK KULLO SUMG ??? IR C 11.26 77.98 DNK SUMG DAG ??? IR C 11.45 84.67 DNK DAG QSPA BHZ IU 60 - a 180.05 88.56 ISC QSPA QSPA BHZ IU 00 - a 180.05 88.56 ISC QSPA QSPA HHZ IU 85 - a 180.05 88.56 ISC QSPA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
