Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta MAJO B?Z IR C 274.10 4.78 MOS MAJO ERM B?Z IR C 352.65 5.71 MOS ERM NMR S?Z IR C 9.41 7.12 MOS NMR TEY S?Z IR C 328.97 10.39 MOS TEY YSS S?Z IR D 354.88 10.65 MOS YSS VLA B?Z IR D 309.40 11.60 MOS VLA MSHR B?Z IR D 305.79 11.80 MOS MSHR USA0B B?Z IR C 313.97 12.14 MOS USA0B TJN B?Z IR D 275.10 13.52 MOS TJN KLR S?Z IR D 328.76 15.73 MOS KLR WHN ??? IR d 265.52 25.46 BJI WHN ULN S?Z IR D 304.58 29.55 MOS ULN GYA ??? IR d 263.51 33.29 BJI GYA BILL B?Z IR D 14.64 34.10 MOS BILL GTA ??? IR c 288.72 34.86 BJI GTA KMI ??? IR d 264.25 37.05 BJI KMI DGZ B?Z IR C 306.64 42.56 MOS DGZ MAKZ BHZ IU 00 + a 303.20 46.54 ISC MAKZ KURK B?Z IR D 308.95 48.07 MOS KURK HDA BHZ AK -- - a 32.54 48.88 ISC HDA RIDG BHZ AK -- - a 33.41 49.81 ISC RIDG BRVK B?Z IR C 313.21 52.70 MOS BRVK AAK B?Z IR C 299.62 52.73 MOS AAK WRAB S?Z IR D 191.03 56.73 MOS WRAB ARU B?Z IR C 319.39 58.31 MOS ARU APA S?Z IR C 336.51 64.20 MOS APA OBN S?Z IR D 324.33 69.94 MOS OBN KBZ B?Z IR D 311.97 73.00 MOS KBZ PFO S?Z IR D 57.46 77.58 MOS PFO ANMO B?Z IR C 51.27 83.33 MOS ANMO sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
