Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CAP2 H?Z IR D 113.09 0.58 UPA CAP2 CAPC H?Z IR D 114.06 0.60 RSNC CAPC CNTA3 S?Z IR D 289.17 1.03 UPA CNTA3 CHPO E?Z IR D 283.58 1.23 UPA CHPO FLAM E?Z IR C 271.25 1.61 UPA FLAM TABO3 S?Z IR C 267.09 1.63 UPA TABO3 PML3 E?Z IR C 274.77 1.69 UPA PML3 ARRA3 S?Z IR C 272.92 1.73 UPA ARRA3 FRIJ E?Z IR C 280.80 1.83 UPA FRIJ CHOR3 E?Z IR C 270.68 1.84 UPA CHOR3 BCIP B?Z IR D 278.59 1.93 RSNC BCIP BCIP B?Z IR D 278.59 1.93 UPA BCIP BCIP BHZ CU 00 - a 278.59 1.93 ISC BCIP MLIR E?Z IR D 280.68 1.96 UPA MLIR PINA E?Z IR D 280.02 2.17 UPA PINA PNME H?Z IR C 260.88 2.43 UPA PNME AZU H?Z IR C 245.40 2.58 UPA AZU UREC H?Z IR D 115.38 2.60 RSNC UREC ACHO3 S?Z IR C 237.20 2.68 UPA ACHO3 PESE3 S?Z IR D 250.36 2.85 UPA PESE3 CACAO H?Z IR C 242.68 3.30 UPA CACAO ZARC H?Z IR D 114.37 3.32 RSNC ZARC GMAL H?Z IR D 251.61 3.48 UPA GMAL HELC H?Z IR D 138.46 3.56 UPA HELC ARGC H?Z IR C 74.66 3.74 RSNC ARGC PTBC H?Z IR D 124.01 4.13 RSNC PTBC BARC S?Z IR D 115.59 5.20 RSNC BARC sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
