Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BARC S?Z IR C 191.37 0.24 RSNC BARC BRRC H?Z IR C 295.37 0.64 RSNC BRRC PAMC S?Z IR C 40.59 0.66 RSNC PAMC RUSC H?Z IR D 176.92 0.94 RSNC RUSC PTBC H?Z IR D 257.54 1.35 RSNC PTBC TAMC H?Z IR C 106.44 1.39 RSNC TAMC SPBC H?Z IR D 218.52 1.50 RSNC SPBC ZARC H?Z IR C 291.04 1.83 RSNC ZARC CTAB S?Z IR D 210.52 2.10 RSNC CTAB ROSC B?Z IR D 210.85 2.31 RSNC ROSC GUY2C H?Z IR C 234.34 2.73 RSNC GUY2C VILC S?Z IR D 191.67 2.76 RSNC VILC PTGC H?Z IR D 159.13 2.80 RSNC PTGC RREF H?Z IR C 229.03 2.92 RSNC RREF ARGC H?Z IR D 339.96 3.20 RSNC ARGC SDV BHZ IU 10 + a 50.40 3.21 ISC SDV SDV BHZ IU 00 + a 50.40 3.21 ISC SDV YOTC H?Z IR C 228.63 4.27 RSNC YOTC GARC H?Z IR D 207.10 5.18 RSNC GARC GARC H?Z IR D 207.10 5.18 RSNC GARC TEIG BHZ IU 00 + a 313.66 19.82 ISC TEIG TEIG BHZ IU 10 + a 313.66 19.82 ISC TEIG MNTX BHZ US 00 + a 313.66 38.95 ISC MNTX ULM BHZ CN -- - a 340.25 47.27 ISC ULM SCHQ BHZ CN -- + a 4.89 48.13 ISC SCHQ sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
