Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta HOPE BHZ II 10 + a 279.40 5.02 ISC HOPE HOPE BHZ II 00 + a 279.40 5.02 ISC HOPE EFI BHZ II 00 + a 269.34 18.17 ISC EFI EFI BHZ II 10 + a 269.34 18.17 ISC EFI SNAA BHZ GE -- + a 156.25 19.53 ISC SNAA MG01 BHZ C1 -- + a 254.71 22.43 ISC MG01 QSPA HHZ IU 85 + a 179.98 34.85 ISC QSPA QSPA BHZ IU 00 + a 179.98 34.85 ISC QSPA QSPA BHZ IU 10 + a 179.98 34.85 ISC QSPA ZON HHZ WA -- + a 292.89 37.15 ISC ZON AC05 HHZ C1 -- + a 293.76 40.14 ISC AC05 AC05 BHZ C1 -- + a 293.76 40.14 ISC AC05 MAW BHZ AU -- - a 144.22 40.95 ISC MAW GO03 BHZ C -- + a 294.92 41.12 ISC GO03 LVC BHZ IU 00 + a 300.45 44.57 ISC LVC LBTB BHZ GT 00 - a 74.53 49.28 ISC LBTB SAML BHZ IU 10 + a 315.31 54.01 ISC SAML SAML BHZ IU 00 + a 315.31 54.01 ISC SAML CASY BHZ IU 00 + a 160.84 54.68 ISC CASY NNA B?Z IR C 299.19 57.52 MOS NNA LSZ BHZ IU 10 + a 70.03 58.58 ISC LSZ LSZ BHZ IU 00 + a 70.03 58.58 ISC LSZ SDV BHZ IU 00 + a 315.67 73.21 ISC SDV SJG BHZ IU 00 + a 323.40 80.04 ISC SJG SJG BHZ IU 10 + a 323.40 80.04 ISC SJG JTS BHZ II 10 + a 303.32 80.76 ISC JTS sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
