Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PB12 H?Z IR C 210.95 1.34 GUC PB12 PB12 BHZ CX -- + a 210.95 1.34 ISC PB12 PB12 HHZ CX -- + a 210.95 1.34 ISC PB12 MNMC H?Z IR C 179.74 1.66 GUC MNMC MNMCX HHZ CX -- + a 179.74 1.66 ISC MNMC LPAZ B?Z IR D 50.56 1.83 GUC LPAZ LPAZ BHZ GT 00 - a 50.56 1.83 ISC LPAZ PSGCX HHZ CX -- + a 192.99 2.18 ISC PSGCX GO01 B?Z IR D 170.03 2.23 GUC GO01 GO01 BHZ C -- - a 170.03 2.23 ISC GO01 PB11 H?Z IR C 181.23 2.29 GUC PB11 PB11 HHZ CX -- + a 181.23 2.29 ISC PB11 PB08 HHZ CX -- - a 170.98 2.70 ISC PB08 TA01 HHZ C1 -- - a 189.94 3.13 ISC TA01 PB02 H?Z IR D 184.07 3.85 GUC PB02 PB07 BHZ CX -- + a 183.55 4.25 ISC PB07 PB03 H?Z IR D 181.74 4.56 GUC PB03 PB03 HHZ CX -- - a 181.74 4.56 ISC PB03 LVC HHZ IU 10 - a 172.87 5.16 ISC LVC LVC BHZ IU 00 + a 172.87 5.16 ISC LVC LVC BHZ IU 10 - a 172.87 5.16 ISC LVC PB06 HHZ CX -- - a 179.68 5.22 ISC PB06 PB05 BHZ CX -- - a 185.89 5.39 ISC PB05 PB05 HHZ CX -- - a 185.89 5.39 ISC PB05 PB10 HHZ CX -- + a 188.26 6.08 ISC PB10 PLCA SHZ GT 10 + a 181.83 23.20 ISC PLCA DBIC BHZ GT 00 + a 75.25 68.28 ISC DBIC sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
