Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta YOTC H?Z IR D 175.15 0.85 RSNC YOTC PIZC H?Z IR C 277.67 0.95 RSNC PIZC ANIL H?Z IR C 108.81 1.07 RSNC ANIL RREF H?Z IR C 86.62 1.07 RSNC RREF CBOC H?Z IR D 21.59 1.10 RSNC CBOC TOLC S?Z IR C 102.91 1.12 RSNC TOLC MALC S?Z IR D 228.18 1.23 RSNC MALC ORTC H?Z IR D 128.28 1.49 RSNC ORTC HELC H?Z IR D 33.31 1.61 RSNC HELC PRAC H?Z IR D 126.13 1.89 RSNC PRAC MARP H?Z IR D 166.89 2.04 RSNC MARP DBBC S?Z IR D 5.44 2.17 RSNC DBBC POPC H?Z IR D 186.46 2.30 RSNC POPC BETC S?Z IR D 155.53 2.35 RSNC BETC SPBC H?Z IR D 70.81 2.47 RSNC SPBC PCON H?Z IR D 179.54 2.49 RSNC PCON GR1C S?Z IR D 223.81 2.52 RSNC GR1C PTBC H?Z IR D 49.01 2.58 RSNC PTBC CHIC H?Z IR C 94.32 2.68 RSNC CHIC GARC H?Z IR D 160.67 2.79 RSNC GARC BBAC H?Z IR D 196.51 2.92 RSNC BBAC BRRC H?Z IR D 49.91 3.51 RSNC BRRC MACC H?Z IR D 136.12 3.71 RSNC MACC TUM BHZ CM 01 - a 217.76 3.77 ISC TUMC UPD2 H?Z IR D 336.79 4.01 UPA UPD2 CHPO E?Z IR D 328.26 5.07 UPA CHPO UPA H?Z IR D 323.24 5.15 UPA UPA ARRA3 S?Z IR D 322.07 5.21 UPA ARRA3 CHOR3 E?Z IR C 320.69 5.23 UPA CHOR3 SDV BHZ IU 00 + a 54.70 7.01 ISC SDV SAML BHZ IU 10 - a 136.04 19.02 ISC SAML REDW BHZ IW 00 - a 326.85 48.95 ISC REDW sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
